A20B-2002-0040/07DR印刷电路板

A20B-2002-0040/07DR印刷电路板

1.产 品 资 料 介 绍：

1. 核心定位：Alpha i 系列伺服放大器主控板，处理高速运动指令并转换为功率驱动信号
2. 通信接口：支持 FSSB 光纤总线，与 FANUC 0i 等 CNC 系统高速通信，抗干扰能力强
3. 反馈处理：接收编码器高频反馈信号，完成位置 / 速度闭环校正，确保定位精度
4. 硬件配置：搭载高速 RISC 处理器，指令执行无抖动，响应速度快
5. 可靠性优化：07DR 版本强化 EMI 屏蔽与信号隔离，抵御功率模块噪声干扰
6. 电源规格：工作电压 24V DC，功耗适配伺服放大器控制单元
7. 保护机制：内置 RAM 校验、通信超时、编码器反馈异常等诊断保护
8. 环境耐受：工作温度 -20℃ 至 +70℃，存储温度 -40℃ 至 +85℃，适应工业现场
9. 结构设计：标准模块化布局，支持现场快速更换，降低维护停机时间
10. 应用场景：适配 FANUC Alpha i 系列伺服驱动器，用于数控机床、机器人、自动化产线等高精度场景

A20B-2002-0040/07DR印刷电路板 产品英文

A20B-2002-0040/07DR is the core control PCB within the FANUC Alpha i series servo amplifier. As the "brain" of the amplifier, it is responsible for processing motion control instructions and feedback loops, and is compatible with mid to high end CNC and automation equipment.

Core positioning: Alpha i series servo amplifier main control board, processing high-speed motion commands and converting them into power drive signals

Communication interface: Supports FSSB fiber optic bus, high-speed communication with CNC systems such as FANUC 0i, strong anti-interference ability

Feedback processing: Receive high-frequency feedback signals from the encoder, complete position/velocity closed-loop correction, and ensure positioning accuracy

Hardware configuration: Equipped with a high-speed RISC processor, instruction execution is jitter free, and response speed is fast

Reliability optimization: 07DR version strengthens EMI shielding and signal isolation to resist power module noise interference

Power specification: Operating voltage 24V DC, power consumption compatible with servo amplifier control unit

Protection mechanism: Built in RAM verification, communication timeout, encoder feedback exception and other diagnostic protections

Environmental tolerance: working temperature -20 ℃ to+70 ℃, storage temperature -40 ℃ to+85 ℃, suitable for industrial sites

Structural design: Standard modular layout, supports quick on-site replacement, reduces maintenance downtime

Application scenario: Suitable for FANUC Alpha i series servo drives, used in high-precision scenarios such as CNC machine tools, robots, automated production lines, etc

As a highly integrated and robust servo control core, it is a commonly used main control board for FANUC's high-end automation equipment, balancing stability and maintenance convenience.
