1.产 品 资 料 介 绍：
- 功能：串口与 ControlNet 双向协议转换，将串口数据映射为 ControlNet I/O，支持 Modbus RTU/ASCII、DF1 等协议。
- 接口：ControlNet 侧 BNC 接口；串口侧 RJ45 接口，速率最高 5 Mbit/s。
- 供电：24 VDC±10%，最大功耗约 300 mA，带反接、短路保护。
- 安装：DIN 导轨安装（EN 50022），IP20 防护，体积紧凑。
- 配置：专用软件无需编程，导入 EDS 文件即可组态，支持拨码设站址。
- 兼容：ControlNet 规范认证，适配罗克韦尔、西门子等主流 PLC。
- 性能：子网光电隔离，MTTF＞550,000 小时，稳定可靠。
- 环境：工作温度 0–55℃，存储 - 40–85℃，湿度 0–95% 无冷凝。
- 典型：配料秤、流量计、变频器等串口设备接入 ControlNet 产线。
结尾
Anybus AB7006控制网适配器 产品英文
AB7006 is an Anybus serial port to ControlNet protocol gateway that enables the interconnection of RS-232/422/485 devices with the ControlNet network, eliminating the need to modify device programs and enabling quick access to automation systems.
Function: Bi directional protocol conversion between serial port and ControlNet, mapping serial port data to ControlNet I/O, supporting protocols such as Modbus RTU/ASCII, DF1, etc.
Interface: BNC interface on the ControlNet side; Serial port side RJ45 interface, with a maximum speed of 5 Mbit/s.
Power supply: 24 VDC ± 10%, maximum power consumption of about 300 mA, with reverse connection and short circuit protection.
Installation: DIN rail installation (EN 50022), IP20 protection, compact size.
Configuration: Specialized software does not require programming, can be configured by importing EDS files, and supports dialing to set station addresses.
Compatibility: ControlNet specification certification, compatible with mainstream PLCs such as Rockwell and Siemens.
Performance: Subnet optoelectronic isolation, MTTF＞550, 000 hours, stable and reliable.
Environment: Working temperature 0-55 ℃, storage -40-85 ℃, humidity 0-95%, no condensation.
Typical: Serial devices such as batching scales, flow meters, and frequency converters are connected to the ControlNet production line.
ending
No modification required, easy to configure, stable and compatible, it is an efficient solution for serial devices to connect to the ControlNet network.
Anybus AB7006控制网适配器 产品展示
