1.产 品 资 料 介 绍：
- 提供32 路 24VDC 数字输入点位，满足多设备状态监测需求
- 支持源型 / 漏型输入可切换，灵活适配各类现场传感器接线
- 每通道内置10ms 硬件滤波，有效抑制工业环境电磁干扰
- 具备8 路慢速计数器功能，可采集低频率脉冲信号
- 采用24VDC 现场供电，无需额外独立电源，布线简洁
- 配合J-RTP00 端子板使用，实现现场信号可靠接线与转接
- 工业级电气隔离设计，保护控制系统免受现场强电干扰
- 通道LED 状态指示灯，实时显示通断状态，便于诊断维护
- 标准导轨式安装，结构紧凑，适配 AMC 系列控制器机架
- 宽温工作范围（-20℃~+70℃），适应恶劣工业工况
- 具备断线检测能力，快速识别传感器或线路故障
- SIL 3 安全等级设计，满足高安全性控制系统要求
- 符合CE、UL、CSA国际安全认证，应用范围广泛
- 信号响应速度快，确保控制系统实时性与稳定性
- 主要用于制造业、电力、化工等行业的自动化信号采集
结尾
J-DIM00数字输入模块 产品英文
J-DIM00 is a 32 channel digital input module launched by Honeywell, which is compatible with advanced multifunctional controller (AMC) systems and used for digital signal acquisition of industrial field switches, sensors, etc. It has both signal input and pulse counting functions.
Provide 32 channels of 24VDC digital input points to meet the needs of multi device status monitoring
Support switchable source/drain input, flexible adaptation to various on-site sensor wiring
Each channel is equipped with a 10ms hardware filter, effectively suppressing electromagnetic interference in industrial environments
Equipped with 8-channel slow counter function, capable of collecting low-frequency pulse signals
Using 24VDC on-site power supply, no additional independent power supply required, simple wiring
Used in conjunction with J-RTP00 terminal board to achieve reliable on-site signal wiring and conversion
Industrial grade electrical isolation design to protect control systems from strong electrical interference on site
Channel LED status indicator light, real-time display of on/off status, convenient for diagnosis and maintenance
Standard rail installation, compact structure, compatible with AMC series controller rack
Wide temperature range (-20 ℃~+70 ℃), suitable for harsh industrial conditions
Capable of detecting wire breaks and quickly identifying sensor or circuit faults
SIL 3 safety level design meets the requirements of high safety control systems
Compliant with CE, UL, CSA international safety certifications, with a wide range of applications
Fast signal response speed ensures real-time and stability of the control system
Mainly used for automated signal acquisition in manufacturing, power, chemical and other industries
ending
J-DIM00, with 32 high-capacity inputs, flexible wiring, reliable anti-interference and safety performance, has become a stable and efficient digital signal acquisition module in Honeywell AMC systems, suitable for various industrial automation monitoring scenarios.
J-DIM00数字输入模块 产品展示
