HP E1406控制器模块

HP  E1406控制器模块

1.产 品 资 料 介 绍：

1. 属于 C 尺寸、单槽 VXI 模块，承担 Slot 0 系统控制器 与 资源管理器 功能。
2. 内置 GPIB（IEEE-488）转 VXI 接口，可通过外部计算机控制整个 VXI 机箱。
3. 搭载 16MHz Motorola 68000 处理器，处理总线命令与仪器通信。
4. 板载 256KB RAM 与 1.75MB Flash 内存，存储固件与驱动程序。
5. 支持 IBASIC 编程语言，可独立运行测试程序，脱离外部电脑。
6. 提供 RS-232 串口，用于终端配置、调试或连接外设。
7. 支持 MXIbus 扩展，可控制多机箱扩展系统。
8. 能将寄存器基仪器翻译为 SCPI 消息基仪器，简化编程。
9. 兼容所有厂商的 消息基 VXI 模块，通用性强。
10. 具备 10MHz 系统时钟 与触发同步功能，统一系统时序。
11. 工业级设计，适配 7×24 小时 连续测试环境。
12. 用于 半导体测试、航空电子、射频 / 微波、数据采集 等自动测试系统。
13. 可与之前的 HP 44701A/44702B 等测量模块同机箱协同工作。
14. 已停产，市场以二手、翻新备件流通。
15. 是传统 VXI 测试系统的 核心控制部件，维护与替换需求稳定。

HP  E1406控制器模块  产品英文

HP E1406A is a VXI bus system controller module launched by HP (Agilent/Keysight), which serves as the core control unit of VXI chassis and is used to build automatic testing systems.

Belonging to C-size, single slot VXI module, responsible for Slot 0 system controller and resource manager functions.

Built in GPIB (IEEE-488) to VXI interface, which can control the entire VXI chassis through an external computer.

Equipped with a 16MHz Motorola 68000 processor, it processes bus commands and communicates with instruments.

Onboard 256KB RAM and 1.75MB Flash memory, storing firmware and drivers.

Supports IBASIC programming language, capable of independently running test programs without the need for an external computer.

Provide RS-232 serial port for terminal configuration, debugging, or connecting peripherals.

Supports MXIbus expansion and can control multiple chassis expansion systems.

Can translate register based instruments into SCPI message based instruments, simplifying programming.

Compatible with all manufacturers' message based VXI modules, with strong universality.

Equipped with 10MHz system clock and trigger synchronization function, unifying system timing.

Industrial grade design, suitable for 7 × 24-hour continuous testing environment.

Used for automatic testing systems such as semiconductor testing, aviation electronics, RF/microwave, data acquisition, etc.

Can work together with previous HP 44701A/44702B measurement modules in the same chassis.

It has been discontinued and the market is dominated by second-hand and refurbished spare parts.

It is the core control component of traditional VXI testing systems, with stable maintenance and replacement requirements.

This module is the key to building a traditional large-scale automatic testing system, responsible for bus management, protocol conversion, and system control.
