Siemens  6AV3617-1JC20-0AX1触摸面板

1.产 品 资 料 介 绍：

Siemens 6AV3617-1JC20-0AX1 触摸 / 操作面板

1. 属于西门子 SIMATIC HMI OP 17/DP 系列，为单色文本 / 图形操作面板，非彩色触摸屏。
2. 采用 LED 背光单色 LCD，支持 4×20 或 8×40 字符 显示，清晰呈现工业参数与状态。
3. 配备 24 个薄膜功能键 + 方向键 + 数字键，操作稳定、防尘耐用，适配工业现场。
4. 内置 256 KB 用户可用内存（Flash+RAM），可存储界面程序与配置数据。
5. 通信接口：MPI / PROFIBUS-DP，最高 1.5 Mbps，无缝对接 S7/M7 系列 PLC。
6. 供电：24 V DC（±20%），额定电流 0.34 A，功耗约 10 W，适配工业标准电源。
7. 防护等级：前面板 IP65、背面 IP20，防水防尘，适合机柜嵌入式安装。
8. 支持 PROFIBUS-DP 从站模式，可直接接入 DP 网络，实现远程监控与数据交互。
9. 兼容 SIMATIC S7-300/400、M7、505 系列 PLC，通用性强。
10. 支持 报警显示、事件记录、参数设置、趋势曲线 等基础 HMI 功能。
11. 安装尺寸：240 mm × 204 mm，标准嵌入式安装，重量约 0.96 kg。
12. 工作温度 0–50°C，适应工业现场宽温环境，长期运行稳定。
13. 具备 CE、UL、FM、EX Zone 2/22 认证，符合全球工业安全标准。
14. 产品已停产，市场以二手、翻新、原装备件为主，用于老旧系统维护替换。
15. 专为传统工控场景设计，操作简单、可靠性高、维护成本低，是老旧生产线 HMI 升级首选。

Siemens  6AV3617-1JC20-0AX1触摸面板  产品英文

Siemens 6AV3617-1JC20-0AX1 Touch/Operation Panel (15 features)

Belonging to the Siemens SIMATIC HMI OP 17/DP series, it is a monochrome text/graphic operation panel with a non color touch screen.

Adopting LED backlit monochrome LCD, supporting 4 × 20 or 8 × 40 character display, presenting industrial parameters and status clearly.

Equipped with 24 film function keys, directional keys, and numeric keys, the operation is stable, dustproof, and durable, suitable for industrial sites.

Built in 256 KB user available memory (Flash+RAM), capable of storing interface programs and configuration data.

Communication interface: MPI/PROFIBUS-DP, up to 1.5 Mbps, seamlessly integrated with S7/M7 series PLCs.

Power supply: 24 V DC (± 20%), rated current 0.34 A, power consumption of approximately 10 W, compatible with industrial standard power supply.

Protection level: IP65 front panel, IP20 back panel, waterproof and dustproof, suitable for embedded installation in cabinets.

Supports PROFIBUS-DP slave mode and can be directly connected to the DP network to achieve remote monitoring and data exchange.

Compatible with SIMATIC S7-300/400, M7, 505 series PLCs, with strong versatility.

Support basic HMI functions such as alarm display, event recording, parameter setting, trend curve, etc.

Installation size: 240 mm × 204 mm, standard embedded installation, weight approximately 0.96 kg.

Working temperature range of 0-50 ° C, suitable for wide temperature environments in industrial sites, and stable long-term operation.

Equipped with CE, UL, FM, and EX Zone 2/22 certifications, in compliance with global industrial safety standards.

The product has been discontinued, and the market mainly consists of second-hand, refurbished, and original spare parts for the maintenance and replacement of old systems.

Specially designed for traditional industrial control scenarios, with simple operation, high reliability, and low maintenance costs, it is the preferred HMI upgrade for old production lines.

Siemens  6AV3617-1JC20-0AX1触摸面板   产品展示
