Siemens 16114-171控制器机架

Siemens  16114-171控制器机架

1.产 品 资 料 介 绍：

1. 适配 APACS+、QUADLOG 等 DCS 系统，属 MODULRAC 系列机架
2. 17 槽位设计，兼容 SMP 系列控制 / 接口 / 输入模块
3. 24V DC 供电，单总线最大 12A，满足多模块功耗需求
4. 工业级宽温：-20℃~+55℃运行，-40℃~+70℃存储
5. 内置背板总线，实现模块间高速数据通信与同步
6. 模块化结构，支持快速安装、扩展与模块热插拔
7. 金属材质，坚固耐用，散热与抗干扰性能优异
8. 带电源与状态指示，便于运行监控与故障排查
9. 符合 UL、CE 等安全认证，适配危险工况（Class I, Div 2）
10. 重量约 3–5kg，标准机柜安装，维护便捷
11. 多用于石化、电力、冶金等大型过程控制 DCS 系统
12. 核心用于老旧系统备件替换与系统扩容

Siemens  16114-171控制器机架 产品英文

Siemens 16114-171 (A5E00281117/09) is a MODULRAC controller rack for Siemens APACS+/QUADLOG systems, providing module installation, bus, and power carriers for the system.

Compatible with DCS systems such as APACS+and QUADLOG, belonging to the MODULRAC series rack

17 slot design, compatible with SMP series control/interface/input modules

24V DC power supply, maximum 12A per bus, meets the power consumption requirements of multiple modules

Industrial grade wide temperature range: -20 ℃~+55 ℃ operation, -40 ℃~+70 ℃ storage

Built in backplane bus for high-speed data communication and synchronization between modules

Modular structure, supporting fast installation, expansion, and module hot plugging

Made of metal material, sturdy and durable, with excellent heat dissipation and anti-interference performance

Equipped with power and status indicators for easy operation monitoring and troubleshooting

Compliant with UL, CE and other safety certifications, suitable for hazardous working conditions (Class I, Div 2)

Weight approximately 3-5kg, standard cabinet installation, easy maintenance

Commonly used in large-scale process control DCS systems such as petrochemicals, power, metallurgy, etc

Core used for replacement of old system spare parts and system expansion

The 16114-171 rack is the core hardware carrier of the APACS+system, with high reliability, strong compatibility, and easy scalability as its core, ensuring the stable operation of the DCS system.

Siemens  16114-171控制器机架 产品展示
