YASKAWA CP-9200SH/SVA伺服驱动器

YASKAWA   CP-9200SH/SVA伺服驱动器

1.产 品 资 料 介 绍：

1. 单模块支持 4 轴伺服独立控制，系统可扩展至 44 轴同步联动。
2. 采用矢量控制算法，支持位置、速度、转矩、差分四种控制模式。
3. 位置控制精度达 ±0.01°，速度控制精度 ±0.02% 额定转速。
4. 响应频率 2kHz，毫秒级动态响应，负载突变下运行稳定。
5. 适配安川 Σ-7 等系列伺服电机，兼容永磁同步、感应电机。
6. 内置 DSP 高速处理核心，运算高效、控制实时性强。
7. 支持 EtherCAT、Modbus、CANopen 等工业总线通信。
8. 集成 IPM 智能功率模块，主回路软启动，降低上电冲击。
9. 具备过流、过压、欠压、过热、编码器异常等全保护。
10. 工作温度 - 10℃~+55℃，IP20 防护，适应工业环境。
11. 模块化设计，可直接集成于 CP-9200SH 机架，扩展灵活。
12. 支持参数拷贝与批量调试，调试维护效率高。
13. 提供专用调试软件，支持在线监控与故障诊断。
14. 额定电压 AC200~240V，适配主流工业供电场景。
15. 结构紧凑、导轨式安装，部署与维护便捷。

YASKAWA   CP-9200SH/SVA伺服驱动器 产品英文

YASKAWA CP-9200SH/SVA is a high-performance servo drive module for the Yaskawa CP-9200SH platform, featuring high precision, high response, and multi axis synchronous control, suitable for precision automated production lines.

Single module supports 4-axis servo independent control, and the system can be extended to 44 axis synchronous linkage.

Adopting vector control algorithm, supporting four control modes: position, speed, torque, and differential.

The position control accuracy reaches ± 0.01 °, and the speed control accuracy is ± 0.02% of the rated speed.

Response frequency of 2kHz, millisecond level dynamic response, stable operation under sudden load changes.

Suitable for Yaskawa ∑ -7 and other series servo motors, compatible with permanent magnet synchronous and induction motors.

Built in DSP high-speed processing core, efficient computation, and strong real-time control.

Supports industrial bus communication such as EtherCAT, Modbus, CANopen, etc.

Integrated IPM intelligent power module, main circuit soft start, reducing power on shock.

It has full protection against overcurrent, overvoltage, undervoltage, overheating, and encoder abnormalities.

Working temperature -10 ℃~+55 ℃, IP20 protection, suitable for industrial environment.

Modular design, can be directly integrated into the CP-9200SH rack, with flexible expansion.

Support parameter copying and batch debugging, with high efficiency in debugging and maintenance.

Provide dedicated debugging software that supports online monitoring and fault diagnosis.

Rated voltage AC200~240V, suitable for mainstream industrial power supply scenarios.

Compact structure, rail mounted installation, easy deployment and maintenance.

YASKAWA CP-9200SH/SVA has become the preferred drive module for high-end motion control scenarios such as robots, CNC machine tools, and electronic manufacturing due to its high precision, reliability, and strong scalability.

YASKAWA   CP-9200SH/SVA伺服驱动器 产品展示

产品视频
