SGMAH-02AAA21伺服电机

SGMAH-02AAA21伺服电机

1.产 品 资 料 介 绍：

1. 额定功率 0.2kW（200W），单相 AC200V 供电，适配小型精密驱动场景。
2. 额定转速 3000r/min，最高转速 5000r/min，转速公差 ±10%。
3. 额定转矩 0.64N・m，瞬时最大转矩 1.92N・m，具备 3 倍过载能力。
4. 采用 13 位相对值串行编码器，位置反馈精度高、响应快。
5. 永磁式励磁，低转子惯量，动态响应快、定位时间短。
6. 轴端为直轴无键结构，安装与传动适配性强。
7. 无制动、无油封配置，结构简洁、维护便捷。
8. 防护等级 IP55（轴贯通部分除外），防尘防溅，适应工业环境。
9. 绝缘等级 B 级，绝缘电阻 DC500V 下≥10MΩ，电气安全可靠。
10. 工作温度 0~40℃，湿度 20~80%（无结露），环境适应性强。
11. 法兰式安装，结构紧凑，节省安装空间。
12. 振动等级 V15，运行平稳、噪音低。
13. 额定连续工作制，满足长期稳定运行需求。
14. 兼容安川 Σ-Ⅱ 系列伺服驱动器，系统匹配度高。
15. 适用于小型机械臂、精密检测平台、半导体设备等精密控制场景。

SGMAH-02AAA21伺服电机 产品英文

SGMAH-02AAA21 is an Yaskawa ∑ - Ⅱ series 200W class small high-precision servo motor, suitable for single-phase AC200V power supply. It focuses on high response, low inertia, and precise positioning, and is widely used in electronic manufacturing and small automation equipment.

Rated power of 0.2kW (200W), single-phase AC200V power supply, suitable for small precision drive scenarios.

Rated speed 3000r/min, maximum speed 5000r/min, speed tolerance ± 10%.

Rated torque 0.64N · m, instantaneous maximum torque 1.92N · m, with 3 times overload capacity.

Using a 13 bit relative value serial encoder, it has high position feedback accuracy and fast response.

Permanent magnet excitation, low rotor inertia, fast dynamic response, and short positioning time.

The shaft end is a straight shaft keyless structure, with strong compatibility for installation and transmission.

No brake, no oil seal configuration, simple structure, easy maintenance.

Protection level IP55 (excluding shaft penetration), dustproof and splash proof, suitable for industrial environments.

Insulation level B, insulation resistance ≥ 10M Ω at DC500V, electrical safety and reliability.

The working temperature is 0-40 ℃, the humidity is 20-80% (without condensation), and the environmental adaptability is strong.

Flange installation, compact structure, saves installation space.

Vibration level V15, smooth operation and low noise.

Rated continuous working system to meet long-term stable operation requirements.

Compatible with Yaskawa ∑ - Ⅱ series servo drives, with high system compatibility.

Suitable for precision control scenarios such as small robotic arms, precision inspection platforms, and semiconductor equipment.

SGMAH-02AAA21 has become the 200W core execution unit in the ∑ - Ⅱ servo system due to its small size, high precision, and high response characteristics.

SGMAH-02AAA21伺服电机 产品展示
