1.产 品 资 料 介 绍：
YASKAWA JANCD‑XTU01B（常被写作 XTUO1B）印刷电路板
1、品牌 / 型号：YASKAWA（安川）JANCD‑XTU01B，属于MP2000 系列运动控制器配套 I/O 与控制板。
2、功能定位：伺服驱动 / 运动控制核心 PCB，负责电流环、速度环、位置环三闭环控制。
3、适配系统：适配安川 MP2300/MP2310/MP2400 等运动 CPU 及伺服单元。
4、I/O 配置：集成16 路数字输入 + 8 路数字输出，DC24V，NPN/PNP 兼容。
5、通信接口：搭载RS‑232/RS‑485/Ethernet，支持 Modbus 等协议，高速联网。
6、供电规格：DC24V±10%，工作电流约 500mA，功耗约 2.5W。
7、控制精度：支持17 位高分辨率编码器，定位精准、动态响应快。
8、保护机制：内置过压、过流、短路、过温多重保护，故障自诊断。
9、环境适应性：工业宽温0℃~+55℃，IP20 防护，耐受振动粉尘。
10、PCB 工艺：FR‑4 基材、多层镀金线路、阻燃阻焊，插拔可靠寿命长。
11、安装方式：标准卡槽机架式安装，即插即用，维护便捷。
12、状态指示：板载LED 状态灯，电源 / 运行 / 故障一目了然。
13、冗余设计：支持冗余电源与多板并联，提升系统连续运行可靠性。
14、尺寸重量：约 200×150×100mm，重约 0.8kg，柜体占用空间小。
15、典型应用：机器人、数控机床、包装机械、半导体设备等高速多轴运动控制场景。
JANCD‑XTU01B 是安川 MP2000 系统的高性能运动控制 PCB，三闭环控制精准、接口丰富、抗干扰强，适用于工业自动化运动控制及备件替换。
JANCD-XTUO1B印刷电路板 产品英文
YASKAWA JANCD-XTU01B (often written as XTUO1B) printed circuit board
1. Brand/Model: YASKAWA (Yaskawa) JANCD-XTU01B, belonging to the MP2000 series motion controller supporting I/O and control board.
2. Functional positioning: Servo drive/motion control core PCB, responsible for three closed-loop control of current loop, speed loop, and position loop.
3. Adaptation system: Suitable for motion CPUs and servo units such as Yaskawa MP2300/MP2310/MP2400.
4. I/O configuration: Integrated 16 digital inputs+8 digital outputs, DC24V, NPN/PNP compatible.
5. Communication interface: Equipped with RS-232/RS-485/Ethernet, supporting Modbus and other protocols, high-speed networking.
6. Power supply specifications: DC24V ± 10%, working current of about 500mA, power consumption of about 2.5W.
7. Control accuracy: Supports 17 bit high-resolution encoders, with precise positioning and fast dynamic response.
8. Protection mechanism: Built in multiple protections for overvoltage, overcurrent, short circuit, and overheating, with self diagnosis of faults.
9. Environmental adaptability: Industrial wide temperature range of 0 ℃~+55 ℃, IP20 protection, resistant to vibration and dust.
10. PCB process: FR-4 substrate, multi-layer gold-plated circuit, flame retardant solder mask, reliable insertion and extraction, long service life.
11. Installation method: Standard card slot rack mounted, plug and play, easy to maintain.
12. Status indicator: Onboard LED status light, power/operation/fault clear at a glance.
13. Redundant design: Supports parallel connection of redundant power supplies and multiple boards to enhance the reliability of continuous system operation.
14. Size and weight: about 200 × 150 × 100mm, weighing about 0.8kg, the cabinet occupies a small space.
15. Typical applications: High speed multi axis motion control scenarios such as robots, CNC machine tools, packaging machinery, semiconductor equipment, etc.
JANCD-XTU01B is a high-performance motion control PCB for the Yaskawa MP2000 system. It features precise three loop control, rich interfaces, and strong anti-interference capabilities, making it suitable for industrial automation motion control and spare parts replacement.
JANCD-XTUO1B印刷电路板 产品展示
