Silicon Graphics 040-1388-002电源控制板
1.产 品 资 料 介 绍：
Silicon Graphics 040-1388-002 电源控制板
- 型号：040-1388-002（SGI 原厂电源控制板）
- 适用：适配 SGI Onyx/Challenge 系列机柜电源
- 核心：专用电源管理 MCU，时序精准可控
- 监测：多通道电压 / 电流 / 温度实时采样
- 保护：过压、欠压、过流、过温硬件保护
- 时序：多阶段上电 / 掉电时序，保护核心板卡
- 通信：与系统主板交互，上报电源状态
- 接口：电源模块对接、系统总线、告警输出
- 负载：支持多电源冗余并联，负载均衡
- 校准：板载电位器，电压精度微调
- 供电：12V/5V 双输入，适配工业电源
- PCB：多层工业级，耐温 - 20℃~+70℃
- 抗干扰：EMI 滤波与屏蔽设计，稳定性强
- 尺寸：标准机架式，专用插槽安装
- 用途：SGI 高端工作站、工业服务器、冗余电源系统
Silicon Graphics 040-1388-002电源控制板 产品英文
Silicon Graphics 040-1388-002 Power Control Board
040-1388-002 is an SGI original industrial grade power monitoring and management board used for high-end workstation/server power systems, responsible for power supply timing, voltage monitoring, and fault protection.
Model: 040-1388-002 (SGI original power control board)
Applicable: Suitable for SGI Onyx/Challenge series cabinet power supply
Core: Dedicated power management MCU, precise and controllable timing
Monitoring: Real time sampling of multi-channel voltage/current/temperature
Protection: Hardware protection against overvoltage, undervoltage, overcurrent, and overheating
Timing: multi-stage power on/off timing to protect the core board
Communication: Interact with the system motherboard and report the power status
Interface: power module docking, system bus, alarm output
Load: Supports redundant parallel connection of multiple power sources and load balancing
Calibration: onboard potentiometer, fine adjustment of voltage accuracy
Power supply: 12V/5V dual input, compatible with industrial power supply
PCB: multi-layer industrial grade, temperature resistance -20 ℃~+70 ℃
Anti interference: EMI filtering and shielding design, strong stability
Size: Standard rack mount, dedicated slot installation
Usage: SGI high-end workstations, industrial servers, redundant power systems
Silicon Graphics 040-1388-002电源控制板 产品展示
