Silicon Graphics SVG80071D I/O控制板
1.产 品 资 料 介 绍：
Silicon Graphics SVG80071D I/O 控制板
- 型号：SVG80071D（SVG 原厂 I/O 控制板）
- 制造商：SVG（Silicon Valley Group），ASML 旗下半导体设备部门
- 类型：工业级数字 / 模拟 I/O 控制板
- 适配设备：SVG 90S、SVG 800 系列光刻 / 涂胶（Coater）设备
- 核心功能：设备 I/O 信号采集、输出控制、传感器对接、状态反馈
- 输入通道：多路数字输入（24V）、模拟输入（0-10V/4-20mA）
- 输出通道：多路继电器输出、晶体管输出，驱动电磁阀 / 电机
- 通信接口：RS-232/485、专用设备总线，对接主控模块
- 板载芯片：专用 I/O 处理 MCU，带固化控制程序
- PCB 规格：工业级多层板，抗电磁干扰、耐高低温
- 防护设计：输入 / 输出光电隔离，防浪涌、防短路
- 安装方式：标准插卡式，适配设备机箱插槽
- 系统适配：SVG 专有实时 OS，与 99-80266-01 主控板配套
- 状态：停产稀缺，二手 / 拆机为主，半导体设备维保关键备件
- 用途：半导体晶圆涂胶、光刻工艺设备 I/O 控制与替换
Silicon Graphics SVG80071D I/O控制板 产品英文
Silicon Graphics SVG80071D I/O Control Board
SVG80071D is an SVG (Silicon Valley Group, later merged into ASML) semiconductor equipment dedicated I/O control board, not an SGI graphics workstation board, used for signal acquisition and peripheral control of lithography/coating equipment.
Model: SVG80071D (SVG original I/O control board)
Manufacturer: SVG (Silicon Valley Group), semiconductor equipment division under ASML
Type: Industrial grade digital/analog I/O control board
Compatible devices: SVG 90S, SVG 800 series lithography/coating (Coater) equipment
Core functions: device I/O signal acquisition, output control, sensor docking, status feedback
Input channels: Multi channel digital input (24V), analog input (0-10V/4-20mA)
Output channels: Multiple relay outputs, transistor outputs, driving solenoid valves/motors
Communication interface: RS-232/485, dedicated equipment bus, docking with the main control module
Onboard chip: dedicated I/O processing MCU with solidified control program
PCB specifications: Industrial grade multi-layer board, resistant to electromagnetic interference and high and low temperatures
Protection design: Input/output optoelectronic isolation, surge protection, short circuit protection
Installation method: Standard plug-in card, compatible with device chassis slot
System adaptation: SVG proprietary real-time OS, compatible with 99-80266-01 main control board
Status: Discontinued and scarce, mainly second-hand/dismantled, critical spare parts for semiconductor equipment maintenance
Usage: Semiconductor wafer coating, photolithography process equipment I/O control and replacement
Silicon Graphics SVG80071D I/O控制板 产品展示
