1.产 品 资 料 介 绍：
- 依托 P697 T 电路架构，实现双通道可控硅触发功能
- 精准匹配电网相位，触发角度调节范围广
- 输出高强度触发脉冲，确保器件稳定导通
- 双通道光电隔离，有效隔绝强弱电干扰
- 内置同步检测电路，实时监测电网运行状态
- 对控制信号整形放大，驱动性能强劲
- 配备浪涌、限流防护，抵御电压电流冲击
- 采用工业级元器件，高低温环境均可正常工作
- 板面做三防处理，防尘防潮，耐腐蚀性佳
- 搭载状态指示灯，运行与故障情况一目了然
- 采用标准接线端子，对接拆装简单便捷
- 整体功耗较低，减轻系统供电负担
- 单通道可独立运作，运行容错性更高
- 电路时序精密，触发误差小，输出稳定
- 兼容同系列设备，可直接替换同型号配件
Ansaldo P697 T 双 SCR 触发电路 PCB 产品英文
Ansaldo P697 T dual SCR trigger circuit PCB is a specialized trigger board for industrial control rectification systems, with precise triggering and reliable operation.
Based on the P697 T circuit architecture, achieve dual channel thyristor triggering function
Accurate matching of grid phase, wide range of trigger angle adjustment
Output high-intensity trigger pulses to ensure stable conduction of the device
Dual channel optoelectronic isolation effectively isolates strong and weak electrical interference
Built in synchronous detection circuit, real-time monitoring of power grid operation status
Control signal shaping and amplification, strong driving performance
Equipped with surge and current limiting protection to resist voltage and current surges
Using industrial grade components, it can work normally in both high and low temperature environments
The board surface is treated with three protections, including dust, moisture, and excellent corrosion resistance
Equipped with status indicator lights, the operation and fault situation are clear at a glance
Using standard wiring terminals, easy and convenient docking and disassembly
Overall low power consumption, reducing the power supply burden on the system
Single channel can operate independently, with higher fault tolerance
Precise circuit timing, small triggering error, stable output
Compatible with devices of the same series, can directly ｒｅｐｌａｃｅ accessories of the same model
Overall, the Ansaldo P697 T dual SCR trigger circuit PCB has stable performance and strong adaptability, making it a core supporting board for industrial rectification and excitation equipment.
Ansaldo P697 T 双 SCR 触发电路 PCB 产品展示
