Ansaldo R01 2H 1000160518印刷电路板
1.产 品 资 料 介 绍：
- 采用高品质 FR-4 基材，绝缘性佳、机械强度高。
- 阻抗控制精准，信号传输稳定、损耗低。
- 多层板结构，集成度高、布线合理、体积紧凑。
- 表面沉金工艺，抗氧化、可焊性好、触点耐用。
- 严格遵循 IEC/EN 60950 安全标准，符合 UL 认证要求。
- 宽温工作设计，适应 - 25℃至 + 71℃工业环境。
- 具备输入 / 输出过压、过流、短路保护功能。
- 板载电压监测电路，可实时监控电源状态。
- 模块化设计，安装便捷、维护简单、通用性强。
- 高导热性能，散热效率好，长期运行温升低。
- 抗电磁干扰能力强，适合复杂工业电磁环境。
- 孔位精度高，插接牢固，适配 Ansaldo 原装接口。
- 采用环保无铅工艺，符合 RoHS 环保规范。
- 出厂 100% 功能测试，品质可靠、故障率低。
- 适配 Ansaldo 传动系统，兼容性强、替换成本低。
Ansaldo R01 2H 1000160518印刷电路板 产品英文
The Ansaldo R01 2H 1000160518 printed circuit board is the core control board in the industrial transmission field, compatible with Ansaldo series frequency conversion and speed regulation systems, with strong stability and high compatibility.
Using high-quality FR-4 substrate, with excellent insulation and high mechanical strength.
Accurate impedance control, stable signal transmission, and low loss.
Multi layer board structure, high integration, reasonable wiring, and compact size.
Surface immersion gold process, anti-oxidation, good weldability, and durable contacts.
Strictly follow the IEC/EN 60950 safety standard and comply with UL certification requirements.
Wide temperature working design, suitable for industrial environments ranging from -25 ℃ to+71 ℃.
Equipped with input/output overvoltage, overcurrent, and short-circuit protection functions.
Onboard voltage monitoring circuit, capable of real-time monitoring of power status.
Modular design, easy installation, simple maintenance, and strong universality.
High thermal conductivity, good heat dissipation efficiency, and low temperature rise during long-term operation.
Strong anti-interference ability, suitable for complex industrial electromagnetic environments.
High hole accuracy, firm insertion, compatible with Ansaldo original interface.
Adopting environmentally friendly lead-free technology and complying with RoHS environmental regulations.
Factory 100% functional testing, reliable quality, low failure rate.
Compatible with Ansaldo transmission system, with strong compatibility and low replacement cost.
The Ansaldo R01 2H 1000160518 printed circuit board, with its reliable performance and industrial grade quality, is the preferred core component for Ansaldo transmission equipment, ensuring long-term stable operation of the system.
Ansaldo R01 2H 1000160518印刷电路板 产品展示
