BOBST 0701218204 is a high-speed digital signal processing board (DSP board) for the 701 rack platform, responsible for motion control, encoder/sensor signal closed-loop operation, and real-time calculation of process data. It is the core computing unit of the equipment.
Original factory number: 0701218204 (701 series core board)
Model adaptation: 701 rack, MASTERFOLD glue box machine, EXPERTCUT die-cutting machine, LB701-UV digital printing machine
Core positioning: Real time motion control+process DSP operation+high-speed data interface three in one core board
Main processing chip: dedicated industrial DSP+FPGA architecture, high real-time performance, low latency
Motion control: multi axis synchronization, position/speed closed-loop, electronic cam/gear synchronization
Signal acquisition: high-speed sampling of analog/digital signals such as encoders, tension, temperature, pressure, etc
Process calculation: alignment, tension, die-cutting/pasting box position compensation, vibration suppression algorithm
Bus communication: 701 dedicated backplane bus, connected to the main control I/O、 Display board
Data interface: high-speed differential, encoder A/B/Z, SSI, RS485, etc
Control output: servo/frequency converter command, PWM output, synchronous trigger signal
Status monitoring: power supply, DSP operation, communication, fault LED diagnosis
Power management: 24V input, onboard DC-DC generates 5V/± 15V/1.2V core voltage
Anti interference design: optocoupler isolation, differential transmission, EMI filtering, surge suppression
Industrial protection: Three proof coating (moisture-proof/dustproof/anti ink), suitable for harsh workshop environments
Reinforcement design: gold-plated thickened gold fingers, seismic resistant structure, suitable for high-speed mechanical vibration
Wide temperature operation: -10 ℃~+60 ℃, tolerant of temperature fluctuations in the workshop
Installation replacement: 701 rack standard slot, same number direct insertion replacement, no debugging, automatic parameter matching
