BOBST C23-01 102022-0704141601控制器模块

BOBST  C23-01 102022-0704141601控制器模块

1.产 品 资 料 介 绍：

BOBST  C23-01 102022-0704141601控制器模块 产品英文

BOBST C23-01 102022-0704141601 Controller Module

BOBST C23-01 102022-0704141601 is a dedicated axis control module for Bost paste box and die-cutting equipment, responsible for the calculation of servo axis actions, signal interaction, and process parameter control of the entire machine.

1. BOBST C23-01 is equipped with a dedicated main control chip that performs real-time calculation of multi axis synchronization, paper positioning, and tension control data

2. Integrated multi-channel encoder pulse interface, collecting servo motor speed and position feedback signals, precise closed-loop control

3. Equipped with RS485 industrial communication port, it can interact with cabinet power board and IO board networking data, and is compatible with the original factory bus protocol

4. Inter board optocoupler isolation circuit, blocking strong and weak electrical interference, and preventing control disorder caused by workshop power grid clutter

5. The entire PCB is coated with three proof paint, which is resistant to ink, dust, and moisture condensation, and is suitable for harsh production conditions in packaging workshops

6. Original gold-plated plug-in terminals, which are resistant to oxidation and virtual connection under continuous vibration conditions, and have excellent wiring stability

7. Integrated overvoltage, overcurrent, and short-circuit triple hardware protection, with output protection components cut off instantly in case of load failure

8. Partition independent circuit layout, single axis circuit failure will not cause the entire board to shut down, reducing production line downtime losses

9. The board is equipped with multiple sets of status indicator lights, which light up intuitively for communication abnormalities and axis control errors, and have high efficiency in troubleshooting

10. Built in large capacity storage chip, permanently retaining device process formula, no need to repeatedly debug parameters when changing product specifications

11. Multiple analog output channels, connected to the drive unit to output speed control signals, precise control of motor torque output

12. ｓｅｌｅｃｔ industrial grade capacitors and surface mount components, operate stably at full load for a long time in a wide temperature range of -20 ℃~+70 ℃

13. Original standard card slot size, electrical control cabinet card slot can be directly inserted and replaced in situ without changing the original wiring circuit

14. Low power circuit architecture, continuous 24-hour production board temperature rise is low, delaying component aging and loss

15. BOBST 102022-0704141601 comes with original firmware, perfectly matching the same series of 704 electronic control system models

Applicable models: Bosch fully automatic box gluing machine, flatbed automatic die-cutting machine with multi axis servo control system.
