Bobst 703-KS控制箱

Bobst 703-KS控制箱

1.产 品 资 料 介 绍：

Bobst 703-KS控制箱 产品英文

Bobst 703-KS control box

1. Original factory equipped Bobst flatbed die-cutting equipment, integrated power supply IO、 Integrated electronic control box for communication and driver boards

2. The cold-rolled steel plate of the box is bent into one piece, and the outer layer is anti-static sprayed with plastic, which is resistant to oil, toner, dust, and workshop moisture corrosion

3. Internal standard DIN rail card slot, compatible with 704, 705, 701 series full specification cards, modular disassembly and assembly

4. Partition independent warehouse layout, separate strong and weak electrical compartments, and eliminate power line interference with control signals

5. The side of the box is equipped with temperature controlled cooling air ducts and optional cooling fans to prevent component overheating and shutdown under high temperature conditions

6. Built in multi-channel filtering power supply circuit, adapted to power grid voltage fluctuations, stable output supply to various boards inside the box

7. The box door is equipped with a sealing strip, with a protection level of IP54, to prevent dust and cutting waste from penetrating and damaging the circuit board

8. Pre installed original wiring terminal layout, in situ full box replacement without secondary wiring changes, quick installation and debugging

9. Reserved communication wiring holes in the box, standardized layout of shielded cables to reduce long-distance signal attenuation faults

10. Equipped with original door lock structure, dust-proof and anti misoperation cover, production site protection ensures the safety of electronic control components

11. Internal grounding busbar centralized design, unified discharge of static electricity, to avoid static electricity breakdown of board chips

12. Reserve fault indicator light positions on the side of the box to visually check the abnormal operation status of each module inside the box

13. Multiple Bobst die-cutting machines in the same series are universal, with strong interchangeability of spare parts for the entire box, and are suitable for retrofitting old equipment

14. Factory full load power on aging detection for the entire machine, with stable electronic control linkage and low overall failure rate

15. Compact body size, compatible with equipment rack reserved installation positions, fixed hole positions standardized by the factory

The Bobst 703-KS control box is a core cabinet accessory for the integrated installation of the control system of the entire Bobst die-cutting equipment

Bobst 703-KS控制箱 产品展示
