1.产 品 资 料 介 绍：
TB83800BK22（GE TB83 系列 限流型塑壳断路器）
- 品牌 / 系列：GE（General Electric），TB83（Tri‑Break）框架。
- 极数 / 额定电流：3 极，800A。
- 额定电压：600V AC。
- 分断能力（AIC）：200kA@480V，工业级高分断。
- 保护类型：热磁脱扣（LI）—— 长延时过载 + 瞬时短路；可互换脱扣单元。
- 核心特性：限流设计，短路时≤5ms 快速切断，限制峰值电流，降低设备冲击。
- 安装方式：螺栓固定（Bolt‑On）。
- 隔离性能：极间 1500V AC、系统间 2500V AC 隔离，安全可靠。
- 环境适应性：工业级宽温、抗振、抗 EMI，适配恶劣工况。
- 标准认证：UL、IEC、CE，符合配电安全规范。
- 机械寿命：长寿命设计，适配长期连续运行。
- 应用场景：工业厂房、商业中心、数据中心、大型设备配电等大电流 / 高短路风险回路。
- 尺寸重量：紧凑型塑壳，约 65kg，适配标准机柜。
- 维护便捷：可更换脱扣器，无需整体拆卸，降低运维成本。
- 安全冗余：限流 + 高分断双重防护，避免故障扩大，保护下游设备。
TB83800BK22限流器 产品英文
TB83800BK22 (GE TB83 series current limiting molded case circuit breaker)
Positioning: General Electric (GE) TB83 series 3-pole 800A current limiting molded case circuit breaker, used for industrial distribution short-circuit/overload protection, with fast current limiting and high breaking capacity.
Brand/Series: GE (General Electric), TB83 (Tri Break) Framework.
Number of poles/rated current: 3 poles, 800A.
Rated voltage: 600V AC.
Breaking ability (AIC): 200kA@480V Industrial grade high score cutoff.
Protection type: Thermal Magnetic Release (LI) - Long Delay Overload+Instantaneous Short Circuit; Interchangeable release unit.
Core features: Current limiting design, fast cut-off within ≤ 5ms in case of short circuit, limiting peak current and reducing equipment impact.
Installation method: Bolt On.
Isolation performance: 1500V AC between poles and 2500V AC between systems, safe and reliable.
Environmental adaptability: Industrial grade wide temperature range, anti vibration, anti EMI, suitable for harsh working conditions.
Standard certification: UL, IEC, CE, in compliance with electrical safety regulations.
Mechanical lifespan: Designed for long service life, suitable for long-term continuous operation.
Application scenarios: High current/high short circuit risk circuits in industrial plants, commercial centers, data centers, and large-scale equipment distribution.
Size and weight: Compact plastic shell, approximately 65kg, suitable for standard cabinets.
Convenient maintenance: The release can be replaced without the need for overall disassembly, reducing operation and maintenance costs.
Security redundancy: dual protection of current limiting and high breaking to prevent the expansion of faults and protect downstream equipment.
TB83800BK22限流器 产品展示
视频展示
