RENISHAW RPI20-P9-XX M-5225-0521-04印刷电路板
1.产 品 资 料 介 绍：
RENISHAW RPI20-P9-XX M-5225-0521-04 印刷电路板
开头
RENISHAW RPI20-P9-XX M-5225-0521-04 印刷电路板为雷尼绍激光干涉编码器配套并行接口板，高精度转换正弦余弦模拟信号，提供超精密位置反馈数据。
支持 1Vpp 正交差分模拟信号输入，适配 RLE 激光测量系统
内置 4096 倍高精度插值运算，定位分辨率可达皮米级
36 位二进制补码并行数据输出，位置数值完整无丢失
单总线最多兼容 7 轴同步采集，多轴设备集中管控
输入带宽最高 6.5MHz，高速运动场景数据无滞后
极低细分误差，SDE 误差控制在 ±0.5nm 以内
板载拨码开关，自由切换输出分辨率参数
实时反馈信号强度、故障报错等状态信息
工业级隔离布线，抵御设备电磁杂波干扰
多层精密 PCB 走线，阻抗稳定保障高频信号完整
紧凑型标准板卡尺寸，适配 VME 工控机架安装
支持外部触发采集，可联动设备同步采样
多重过压、静电防护，适配精密设备车间工况
低功耗芯片方案，长时间连续运行温升可控
标准化端子插槽，拆装维护无需复杂调试
结尾
RENISHAW RPI20-P9-XX M-5225-0521-04 印刷电路板测量精度高、多轴适配性强，是精密机床、检测设备激光位移反馈核心配套板卡。
RENISHAW RPI20-P9-XX M-5225-0521-04印刷电路板 产品英文
RENISHAW RPI20-P9-XX M-5225-0521-04 Printed Circuit Board
beginning
RENISHAW RPI20-P9-XX M-5225-0521-04 printed circuit board is a parallel interface board for Renishaw laser interferometer encoder, which can convert sine and cosine analog signals with high precision and provide ultra precision position feedback data.
Support 1Vpp orthogonal differential analog signal input, compatible with RLE laser measurement system
Built in 4096 times high-precision interpolation operation, positioning resolution can reach picometer level
36 bit binary complement parallel data output, complete position values without loss
Single bus compatible with up to 7-axis synchronous acquisition, centralized control of multi axis devices
Input bandwidth up to 6.5MHz, no lag in high-speed motion scene data
Extremely low subdivision error, SDE error controlled within ± 0.5nm
Onboard dip switch, freely switch output resolution parameters
Real time feedback on signal strength, fault reports, and other status information
Industrial grade isolation wiring to resist electromagnetic interference from equipment
Multi layer precision PCB routing ensures impedance stability and integrity of high-frequency signals
Compact standard board size, compatible with VME industrial control rack installation
Support external trigger collection, can synchronize sampling with linked devices
Multiple overvoltage and electrostatic protection, suitable for precision equipment workshop working conditions
Low power chip solution, long-term continuous operation with controllable temperature rise
Standardized terminal slots, no need for complex debugging during disassembly and maintenance
ending
RENISHAW RPI20-P9-XX M-5225-0521-04 printed circuit board has high measurement accuracy and strong multi axis adaptability. It is a core supporting board for laser displacement feedback in precision machine tools and detection equipment.
RENISHAW RPI20-P9-XX M-5225-0521-04印刷电路板 产品展示
视频展示
