1.产 品 资 料 介 绍：
TEL PDS-BX02S1421 印刷电路板
- 高密度多层布线，集成控制与信号传输线路
- 精密阻抗走线，高速信号传输无干扰
- 加厚铜箔线路，大电流负载不易发热
- 全板三防涂层，防潮防尘耐腐蚀
- 标准化板卡尺寸，机槽直接插拔替换
- 预留多组测试点位，故障检测便捷
- 金属化高可靠过孔，层间连接稳定
- 耐高温基材，设备长时间运行不变形
- 清晰丝印元件标号，检修更换简单
- 低微粒生产工艺，适配无尘晶圆车间
- 抗电磁干扰设计，多板同框互不影响
- 多重回路防护，短路、过载不易烧板
- 原厂标准接口，完美匹配 SE2000 系列机台
- 焊接焊点牢固，抗震耐产线震动环境
- 出厂全功能通电检测，出厂一致性高结尾：TEL PDS-BX02S1421 耐用易更换，是 TEL 半导体刻蚀设备核心配套电路板。
TEL PDS-BX02S1421印刷电路板 产品英文
TEL PDS-BX02S1421 Printed Circuit Board
Introduction: TEL PDS-BX02S1421 is a dedicated main control PCB board for Tokyo electronic semiconductor equipment, compatible with etching machines, stable circuits, and clean processes.
High density multi-layer wiring, integrated control and signal transmission lines
Precise impedance routing, interference free high-speed signal transmission
Thickened copper foil circuit, less likely to generate heat for high current loads
Three proof coating on the entire board, moisture-proof, dustproof, and corrosion-resistant
Standardized board size, direct insertion and replacement of machine slots
Reserve multiple sets of testing points for convenient fault detection
Metallized high reliability via, stable interlayer connection
High temperature resistant substrate, equipment operates for a long time without deformation
Clear silk screen component labeling, easy maintenance and replacement
Low particle production process, suitable for dust-free wafer workshops
Anti electromagnetic interference design, multiple boards in the same frame do not affect each other
Multiple circuit protection, short circuit and overload are not easy to burn the board
Original factory standard interface, perfectly matched with SE2000 series machines
The welding points are firm and resistant to seismic and production line vibration environments
Factory full function power on testing with high consistency
Conclusion: TEL PDS-BX02S1421 is durable and easy to ｒｅｐｌａｃｅ, and is the core supporting circuit board for TEL semiconductor etching equipment.
