ACS CMba2B24N0NEBC240-ORB1 运动控制模块
1.产 品 资 料 介 绍：
CMba2B24N0NEBC240-ORB1 运动控制模块产品特点
- 内置双轴伺服驱动，单轴输出电流稳定，适配直线 / 音圈电机
- 20kHz 高速伺服闭环采样，纳米级定位抖动，运动顺滑无振动
- 作为 EtherCAT 主站，可拓展控制多轴，时钟同步精度高
- 支持正交、正余弦、绝对值多种编码器信号接入
- 内置先进龙门解耦算法，消除交叉轴运动偏移误差
- S 型平滑轨迹规划，高速启停无冲击，保护精密载台
- 搭载振动抑制算法，规避机台共振，提升重复定位精度
- 多通讯接口：以太网、RS232，对接上位机与设备 PLC
- 独立 24V 控制供电，断电保留运动工艺参数
- 硬件多重保护：过流、过压、超温、电机短路自动停机
- 丰富数字 / 模拟 IO 点位，支持位置触发、真空、气路联动
- ACSPL + 多任务编程，兼容 G 代码、PLC 标准程序语言
- 铝合金一体式散热壳体，长时间满载温升低
- 模块化标准机柜安装，拆装替换便捷
- 出厂伺服参数校准，上机即可适配精密运动平台ACS CMba2B24N0NEBC240-ORB1 运动控制模块是半导体检测、光刻、镀膜设备高精度载台核心控制部件。
ACS CMba2B24N0NEBC240-ORB1 运动控制模块 产品英文
CMba2B24N0NEBC240-ORB1 Motion Control Module Product Features
ACS CMba2B24N0NEBC240-ORB1 is an integrated EtherCAT motion control module specifically designed for semiconductor precision platforms. It integrates servo drive and main control, and is compatible with wafer pre alignment and inspection table equipment.
Built in dual axis servo drive, stable single axis output current, suitable for linear/voice coil motors
20kHz high-speed servo closed-loop sampling, nanometer level positioning jitter, smooth and vibration free motion
As the EtherCAT master station, it can expand control over multiple axes and has high clock synchronization accuracy
Support the integration of multiple encoder signals including orthogonal, sine cosine, and absolute values
Built in advanced gantry decoupling algorithm to eliminate cross axis motion offset errors
S-shaped smooth trajectory planning, high-speed start stop without impact, protecting precision stages
Equipped with vibration suppression algorithm to avoid machine resonance and improve repeat positioning accuracy
Multiple communication interfaces: Ethernet RS232， Connect the upper computer with the equipment PLC
Independent 24V control power supply, power-off retains motion process parameters
Multiple hardware protections: overcurrent, overvoltage, overtemperature, motor short circuit, automatic shutdown
Rich digital/analog IO points, supporting position triggering, vacuum, and gas path linkage
ACSPL+multitasking programming, compatible with G-code and PLC standard programming language
Aluminum alloy integrated heat dissipation shell, low temperature rise under full load for a long time
Modular standard cabinet installation, easy disassembly and replacement
Factory servo parameter calibration, can be adapted to precision motion platforms on the machine
The ACS CMba2B24N0NEBC240-ORB1 motion control module is the core control component for high-precision stages in semiconductor detection, lithography, and coating equipment.
ACS CMba2B24N0NEBC240-ORB1 运动控制模块 产品展示
