1.产 品 资 料 介 绍：
ACS MC4U-02100 自动化控制器模块
- 内置双轴伺服驱动，单模块独立管控两轴电机
- 高速 EtherCAT 总线，通讯周期短、实时性强
- 支持直线、圆弧插补，运动轨迹平稳低抖动
- 兼容多种编码器，高精度位置反馈采集
- 40kHz 高频 PWM 控制，电机运行噪音更小
- 多重硬件保护，过流过温过载自动停机
- 模块化插拔结构，扩容、检修拆装简便
- 支持 ACSPL + 与 PLCopen 双编程模式
- 自带多路数字 IO，可对接传感器与限位开关
- 金属屏蔽柜体，抵御车间电磁干扰
- 0-55℃宽温工作，可 24 小时连续运行
- 多机组网拓展，整套系统最多扩展 64 轴
- 集成专用调试软件，参数设置直观便捷
- 通用宽电压供电，适配各类设备供电工况
- 具备故障自检功能，快速输出异常代码结尾：ACS MC4U-02100 集成度高、定位精准，广泛用于半导体检测、激光加工、精密点胶设备。
ACS MC4U-02100 自动化控制器模块 产品英文
ACS MC4U-02100 Automation Controller Module
Introduction: ACS MC4U-02100 is a 2-axis modular drive control integrated motion controller, equipped with EtherCAT bus, suitable for precision automation platform positioning control.
Built in dual axis servo drive, single module independent control of two axis motors
High speed EtherCAT bus with short communication cycle and strong real-time performance
Support linear and circular interpolation, with smooth and low shaking motion trajectory
Compatible with multiple encoders, high-precision position feedback acquisition
40kHz high-frequency PWM control, resulting in lower motor operating noise
Multiple hardware protections, automatic shutdown due to overcurrent, overheating, and overload
Modular plug-in structure, easy expansion, maintenance and disassembly
Supports ACSPL+and PLCopen dual programming modes
Equipped with multiple digital IO channels, it can be connected to sensors and limit switches
Metal shielded cabinet to resist electromagnetic interference in the workshop
0-55 ℃ wide temperature operation, capable of continuous operation for 24 hours
Multi unit network expansion, the entire system can expand up to 64 axes
Integrated specialized debugging software, with intuitive and convenient parameter settings
Universal wide voltage power supply, suitable for various equipment power supply conditions
Equipped with fault self checking function, quickly output abnormal codes
Conclusion: ACS MC4U-02100 has high integration and precise positioning, and is widely used in semiconductor testing, laser processing, and precision dispensing equipment.
ACS MC4U-02100 自动化控制器模块 产品展示
视频展示
