1.产 品 资 料 介 绍：
ETEL EA-P2M-300-4 位置控制器
- 双轴独立驱动通道，单轴持续输出 7.5A 电流适配直线电机
- 支持 EtherCAT 高速总线，500μs 实时周期，多轴同步误差极小
- 兼容 EnDat、TTL、1Vpp 多类编码器，支持双编码器闭环反馈
- 内置齿槽力、摩擦力补偿算法，运动运行顺滑无抖动
- 具备高速位置触发捕捉功能，适配视觉同步定位工况
- 搭载专用 ComET 调试软件，参数整定、波形观测操作简单
- 48-340V 宽直流母线电压输入，适配各类工业供电单元
- 10kHz/20kHz 可调 PWM 载波，低速扭矩输出稳定充沛
- 集成 STO 安全切断回路，超行程、故障快速停机防护
- 内置运动轨迹滤波，有效抑制平台震动，缩短整定时间
- USB 调试接口，支持固件升级、程序参数快速备份拷贝
- 多路隔离数字输入输出，可外接限位、探针传感信号
- 金属屏蔽一体化壳体，抗电磁干扰适配无尘精密产线
- DIN 导轨标准安装结构，电控柜内排布紧凑节省空间
- 工业级长效元器件，半导体、光学设备长期满载稳定运行ETEL EA-P2M-300-4 位置控制器定位精度高、同步性能强，是精密直线运动平台专用伺服控制备件
ETEL EA-P2M-300-4 位置控制器 产品英文
ETEL EA-P2M-300-4 Position Controller
Dual axis independent drive channel, single axis continuous output 7.5A current compatible with linear motor
Supports EtherCAT high-speed bus, 500 μ s real-time cycle, minimal multi axis synchronization error
Compatible with EnDat, TTL, 1Vpp multi class encoders, supporting dual encoder closed-loop feedback
Built in tooth slot force and friction compensation algorithms, smooth and vibration free motion operation
Equipped with high-speed position triggering capture function, suitable for visual synchronous positioning conditions
Equipped with dedicated ComET debugging software, parameter tuning and waveform observation operations are simple
48-340V wide DC bus voltage input, suitable for various industrial power supply units
10kHz/20kHz adjustable PWM carrier, stable and abundant low-speed torque output
Integrated STO safety cut-off circuit, rapid shutdown protection against overtravel and faults
Built in motion trajectory filtering effectively suppresses platform vibration and shortens setting time
USB debugging interface, supports firmware upgrade, quick backup and copying of program parameters
Multi channel isolated digital input/output, capable of external limit and probe sensing signals
Metal shielding integrated shell, anti electromagnetic interference compatible with dust-free precision production line
DIN rail standard installation structure, compact layout inside the electrical control cabinet, saving space
Industrial grade long-lasting components, semiconductor and optical equipment operate stably at full load for a long time
ETEL EA-P2M-300-4 position controller has high positioning accuracy and strong synchronization performance, and is a specialized servo control spare part for precision linear motion platforms
ETEL EA-P2M-300-4 位置控制器 产品展示
