AVIVA LIN AT71-M4CL8007- BA2 线性工业相机
1.产 品 资 料 介 绍：
AVIVA LIN AT71-M4CL8007-BA2 线性工业相机
- 8192 像素高清线阵 CCD 感光芯片，7μm 方形像元，成像细节分辨力极强
- Medium 规格 Camera Link 高速接口，4Tap 并行输出，峰值像素传输速率高
- 内置强光抗晕溢电路，高光场景无拖影，适配高亮度工件表面检测
- 100% 开口率感光阵列，感光效率高，弱光环境成像信噪比表现优异
- 支持 0-24dB 连续可调模拟增益，0.04dB 精细步进，亮度适配灵活
- 8bit/10bit 双模式图像输出，可根据检测需求切换灰度采样精度
- 内置平场校正功能，消除镜头光照不均，保证全线灰度均匀一致
- 内触发、外触发双工作模式，可与输送平台、伺服同步采集图像
- DC12-24V 宽压单电源供电，适配自动化设备通用供电回路
- 一体式金属散热鳍片结构，长时间连续扫描温升稳定无热漂移
- F 型标准镜头接口，兼容各类工业远心、微距检测镜头，换装便捷
- 串行串口参数调控，可远程修改曝光、增益、触发等相机参数
- 全金属屏蔽机身，抵御变频器、射频电磁干扰，无尘车间稳定运行
- 紧凑型标准化机身尺寸，设备机架安装占用空间小，集成方便
- 原厂老化整机测试，适配 PCB、玻璃、薄膜高精度表面瑕疵检测产线AVIVA LIN AT71-M4CL8007-BA2 线性工业相机分辨率高、成像稳定，是高精度卷材、板材表面视觉检测专用线阵相机备件
AVIVA LIN AT71-M4CL8007- BA2 线性工业相机 产品英文
AVIVA LIN AT71-M4CL8007-BA2 Linear Industrial Camera
8192 pixel high-definition linear array CCD photosensitive chip, 7 μ m square pixel, with extremely strong imaging detail resolution
Medium specification Camera Link high-speed interface, 4Tap parallel output, high peak pixel transfer rate
Built in strong light anti glare circuit, no ghosting in high light scenes, suitable for high brightness workpiece surface detection
100% aperture rate photosensitive array, high photosensitive efficiency, excellent signal-to-noise ratio performance in low light environment imaging
Supports 0-24dB continuously adjustable analog gain, 0.04dB fine step, flexible brightness adaptation
8-bit/10bit dual-mode image output, with the ability to switch grayscale sampling accuracy according to detection requirements
Built in flat field correction function, eliminating uneven lens lighting and ensuring uniform grayscale throughout the entire line
Dual working mode of internal trigger and external trigger, capable of synchronously capturing images with the conveying platform and servo
DC12-24V wide voltage single power supply, suitable for general power supply circuits of automation equipment
Integrated metal heat dissipation fin structure, stable temperature rise without thermal drift during long-term continuous scanning
F-type standard lens interface, compatible with various industrial telecentric and macro detection lenses, easy to ｒｅｐｌａｃｅ
Serial port parameter control, allowing remote modification of camera parameters such as exposure, gain, trigger, etc
All metal shielded body, resistant to frequency converter, RF electromagnetic interference, stable operation in dust-free workshop
Compact standardized body size, small space occupation for equipment rack installation, easy integration
Original factory aging machine testing, compatible with high-precision surface defect detection production lines for PCB, glass, and film
AVIVA LIN AT71-M4CL8007-BA2 linear industrial camera has high resolution and stable imaging, and is a spare part for high-precision linear array cameras used for visual inspection of coil and sheet surfaces
AVIVA LIN AT71-M4CL8007- BA2 线性工业相机 产品展示
