1.产 品 资 料 介 绍：

# TEL 2L80-000952-V2 射频滤波器

TEL 2L80-000952-V2 是东京电子半导体刻蚀沉积设备专用射频滤波配件，净化射频信号，保障工艺稳定。

1. 适配 TEL 半导体机台，匹配 2L80-000952-V2 射频回路

2. 低插入损耗，目标射频信号传输损耗小

3. 带外高抑制，滤除杂波、谐波干扰信号

4. 标准 50Ω 阻抗，射频回路匹配无反射

5. 金属屏蔽外壳，隔绝腔体电磁干扰

6. 耐受工艺高频功率，长期工作不失效

7. 密封防尘结构，适配无尘洁净车间

8. 宽温稳定特性，腔体高低温工况性能不变

9. 镀金射频端子，连接稳定无信号跳变

10. 抑制射频串扰，保护机台传感与控制板

11. 小型紧凑壳体，机柜狭小空间易安装

12. 抗震动结构，设备运行震动不偏移参数

13. 一体化集成设计，无需额外调试校准

14. 多重绝缘防护，杜绝射频漏电隐患

15. 出厂射频全频段检测，滤波性能统一

综上，TEL 2L80-000952-V2 射频滤波器滤波效果强、阻抗匹配精准，可净化射频电源输出信号，是半导体薄膜工艺机台必备射频备件。

TEL 2L80-000952-V2 射频滤波器  产品英文

#TEL 2L80-000952-V2 RF Filter

TEL 2L80-000952-V2 is a specialized RF filtering accessory for Tokyo Electronic Semiconductor Etching and Deposition Equipment, which purifies RF signals and ensures process stability.

1. Compatible with TEL semiconductor machine, matched with 2L80-000952-V2 RF circuit

2. Low insertion loss, small transmission loss of target RF signal

3. Out of band high suppression, filtering out clutter and harmonic interference signals

4. Standard 50 Ω impedance, RF circuit matching without reflection

5. Metal shielding shell to isolate electromagnetic interference from the cavity

6. Tolerate high-frequency power of the process and work for a long time without failure

7. Sealed dust-proof structure, suitable for dust-free clean workshops

8. Wide temperature stability characteristics, unchanged performance under high and low temperature conditions of the cavity

9. Gold plated RF terminal, stable connection without signal jump

10. Suppress RF crosstalk and protect machine sensors and control boards

11. Small and compact shell, easy to install in narrow space of cabinet

12. Anti vibration structure, equipment operation vibration does not deviate parameters

13. Integrated design with no need for additional debugging or calibration

14. Multiple insulation protection to eliminate radio frequency leakage hazards

15. Factory RF full band testing with uniform filtering performance

Overall, TEL 2L80-000952-V2 RF filter has strong filtering effect, accurate impedance matching, and can purify RF power output signals. It is an essential RF spare part for semiconductor thin film process machines.

TEL 2L80-000952-V2 射频滤波器   产品展示
