Shinko SBX93-100005-C2 印刷电路板

Shinko SBX93-100005-C2 印刷电路板

1.产 品 资 料 介 绍：

Shinko SBX93-100005-C2 印刷电路板   产品英文介绍

Shinko SBX93-100005-C2 Printed Circuit Board

1. Industrial equipment specific PCB board with high substrate strength

2. Multi layer wiring structure to achieve separation of power and signal lines

3. Strict impedance control ensures stable transmission of high-speed signals

4. Excellent surface treatment process and high welding reliability

5. Through hole electroplating process ensures continuous and stable interlayer conductivity

6. The solder mask ink coating is uniform, protecting the circuit from corrosion

7. High precision aperture machining, compatible with various types of connector pins

8. Reserve multiple test pads for easy hardware testing and debugging

9. Optimization of routing layout to reduce signal crosstalk between lines

10. Good temperature resistance and adaptability to internal temperature changes of the equipment

11. Strengthening the edge of the board to reduce physical damage caused by disassembly and assembly

12. Insulation performance meets the standard, avoiding the risk of leakage under high voltage

13. The solder pads of onboard components are neat and easy to install and assemble

14. Compatible with Shinko original equipment, with high firmware and hardware compatibility

15. Mostly used for internal signal control circuits in semiconductor equipment

The Shinko SBX93-100005-C2 printed circuit board is the core circuit board for signal interaction within the device.

Shinko SBX93-100005-C2 印刷电路板 产品展示
