1.产 品 资 料 介 绍：

# Dtims CPB4612‑LF 控制板

Dtims CPB4612‑LF 是 6U CompactPCI 工业主控控制板，适配半导体、工控设备机框系统。

1. Dtims CPB4612‑LF 符合 PICMG 工业总线标准，机框插拔式安装

2. 板载双千兆网口，满足高速数据传输通讯需求

3. 搭载 PMC 扩展插槽，可灵活加装子板扩展功能

4. 支持 ECC 内存，数据运算运行稳定性更强

5. Dtims CPB4612‑LF 集成看门狗定时器，死机自动复位保护系统

6. 支持 IPMI 设备管理，可远程监控板卡运行状态

7. 板载图形处理单元，可输出显示信号

8. Dtims CPB4612‑LF 支持 IDE 存储接口，可外接硬盘存储数据

9. 6U 单槽结构，占用机箱单槽位，节省机柜空间

10. 金手指背板对接，信号与供电一体化接入

11. Dtims CPB4612‑LF 宽温工作设计，适配机柜内部高低温环境

12. 电路做 EMC 优化，抵抗工业现场电磁干扰

13. 支持长时间不间断 7×24 小时连续运行

14. Dtims CPB4612‑LF 无铅 LF 版本，满足工业环保工艺要求

15. 标准化硬件接口，备件替换简单方便

Dtims CPB4612‑LF 控制板作为 CompactPCI 机框核心主控板，为工业设备提供运算、通讯与外设扩展能力。

Dtims CPB4612-LF 控制板   产品英文介绍

# Dtims CPB4612-LF Control Board

Dtims CPB4612-LF is a 6U CompactPCI industrial main control board, suitable for semiconductor and industrial equipment chassis systems.

1. Dtims CPB4612-LF complies with the PICMG industrial bus standard and is installed in a chassis with plug-and-play functionality.

2. It is equipped with dual gigabit network ports, meeting the requirements for high-speed data transmission and communication.

3. It has a PMC expansion slot, allowing for flexible addition of sub-boards to expand functions.

4. It supports ECC memory, making data operation more stable.

5. Dtims CPB4612-LF integrates a watchdog timer, automatically resetting the system in case of a crash.

6. It supports IPMI device management, enabling remote monitoring of the board's operation status.

7. It is equipped with a graphics processing unit, capable of outputting display signals.

8. Dtims CPB4612-LF supports IDE storage interfaces, allowing for external hard disk storage of data.

9. It has a 6U single-slot structure, occupying a single slot of the chassis, saving cabinet space.

10. The gold finger backplane is connected, with integrated signal and power supply access.

11. Dtims CPB4612-LF is designed for wide temperature operation, suitable for the internal high and low temperature environment of the chassis.

12. The circuit is optimized for EMC, resisting industrial site electromagnetic interference.

13. It supports long-term uninterrupted 7×24-hour continuous operation.

14. Dtims CPB4612-LF is a lead-free LF version, meeting industrial environmental protection process requirements.

15. Standardized hardware interfaces, making spare parts replacement simple and convenient.

The Dtims CPB4612-LF control board serves as the core main control board of the CompactPCI chassis, providing computing, communication, and peripheral expansion capabilities for industrial equipment.

Dtims CPB4612-LF 控制板 产品展示
