1.产 品 资 料 介 绍：
NI PXI-6115同步采样模块 产品英文介绍
The NI PXI-6115 synchronous sampling module is a multifunctional DAQ acquisition module from the NI S series, equipped with an independent ADC to achieve multi-channel synchronous acquisition. It integrates analog input/output, digital IO, and counter, and is compatible with PXI chassis. It is commonly used for transient signal acquisition and excitation response testing.
Product Features
1. Each channel has an independent 12 bit ADC, with a maximum synchronous sampling rate of 10MS/s for a single channel, resulting in small channel phase errors
2. Comes with a programmable third-order Bessel anti aliasing filter to suppress high-frequency noise during data collection
3. Integrate 2 analog outputs, 8 bidirectional DIOs, and 2 24 bit counter timers
4. Support PXI triggered bus, can cascade multiple modules, and achieve large-scale multi card synchronous measurement
5. Equipped with NI DAQmx driver, convenient programming configuration, suitable for various automated testing systems
Application Fields
1. Radar, sonar, and ultrasonic signal acquisition testing
2. Transient signal testing of 42V electrical system for automobiles
3. Measurement of short-term transient dynamic signals such as impact and trajectory
4. Aerospace vibration and acoustic synchronization testing
5. Construction of incentive response closed-loop testing system
6. Signal capture and recording in high-energy physics experiments
7. Multi parameter synchronous monitoring of motors and power equipment
8. High speed dynamic data acquisition in scientific research laboratories
9. Industrial equipment fault diagnosis and vibration analysis
10. Digital acquisition of RF and IF signals
NI PXI-6115 is suitable for high-speed multi-channel synchronous testing scenarios and is a commonly used PXI spare part for dynamic signal acquisition.
NI PXI-6115同步采样模块 产品展示
视频展示
