1.产 品 资 料 介 绍：
1SFA664001R1001电弧监测仪 产品英文介绍
1SFA664001R1001 Arc Monitoring Instrument (TVOC-2-240) is the main control unit of ABB arc protection system, which collects optical signals from fiber optic probes, quickly detects internal arc faults in switchgear, and triggers tripping.
Product Features:
1. Millisecond level response, detecting arc light instantly outputs a trip command, reducing the risk of equipment damage and personnel injury.
2. Comes with 10 fiber optic inputs, expandable channels, and supports zone selective protection.
3. Integrate HMI human-machine interface to view fault records and configure protection parameters.
4. SIL2 safety level certification, industrial grade hardware, suitable for high temperature and dust environments in switchgear.
5. It has event log storage and can save multiple fault records for accident analysis.
Application fields:
6. Arc light protection system for medium and low voltage switchgear.
7. Power plant power distribution cabinet.
8. Low voltage distribution system in petrochemical plants.
9. Metallurgical workshop switchgear protection unit.
10. Complete equipment for power supply and distribution in data centers.
11. Rail transit distribution control cabinet.
12. Mining underground power distribution protection system.
13. Large commercial complex distribution room.
14. Replacement of spare parts for ABB TVOC-2 arc protection system.
15. New energy power station distribution protection equipment.
Product Parameters:
16. Power supply: 100-240VAC/100-250VDC wide voltage input.
17. Optical input: Built in 10 fiber optic probe interfaces.
18. Function: Arc light detection, fault recording, multi zone trip output.
ABB 1SFA664001R1001 arc monitoring device is the core device for arc protection in switchgear. It quickly cuts off the power supply in case of arc fault, ensuring the safety of the distribution system
1SFA664001R1001电弧监测仪 产品展示
视频展示
