IS200EGPAG1ABC放大器板

IS200EGPAG1ABC放大器板

1.产 品 资 料 介 绍：

IS200EGPAG1ABC放大器板 产品英文介绍

IS200EGPAG1ABC amplifier board

Product Features

Six independent pulse amplification outputs drive SCR thyristor rectifier bridge

Integrated Bridge Temperature, Airflow, and Current Collection for Multi Dimensional Monitoring of Operating Conditions

The onboard status indicator light visually displays channel operation and fault information

Flexible hardware jumper configuration to adapt to different excitation system schemes

Standard card rack structure supports quick disassembly and maintenance of control cabinets

Product application areas

Excitation Control System for Gas Turbine EX2100

Excitation regulation unit for steam turbine generator set

Power Control System of Combined Cycle Power Plant

Synchronous phase-shifting camera excitation matching cabinet

Mark VI gas turbine control system

Control cabinet for large thermal power generation units

Excitation device for pumped storage unit

Excitation system for industrial high-power generators

Power plant turbine unit protection measurement and control system

Power rectifier bridge drive unit for power plants

Product Specifications

Output channel six SCR pulse triggering channels

Power supply specification: Onboard DC 5V power supply

Adaptation System Mark VI Speedtronic Control System

The IS200EGPAG1ABC amplifier board serves as the core board for pulse drive in the excitation system, amplifying and controlling the pulse drive power rectifier unit to ensure stable and reliable excitation regulation of the generator set.

IS200EGPAG1ABC放大器板 产品展示

视频展示
