1.产 品 资 料 介 绍：
Physik E-503K004高压放大器 产品英文介绍
Physik E-503K004 High Voltage Amplifier
Product Features
Three channel independent piezoelectric drive with stable output voltage gain and excellent linearity
Built in short circuit protection and overheat protection automatically cut off output in case of abnormality
Support DC offset adjustment and fine tune static positioning reference voltage
3U modular board compatible with E500 series chassis for quick insertion and replacement
Low noise amplification output suitable for precise control of nanoscale piezoelectric platforms
Product application areas
Precision focusing displacement mechanism of semiconductor lithography machine
Laser scanning galvanometer piezoelectric driving unit
Optical adaptive mirror adjustment system
Precision Motion Control of Nano Positioning Platform
High speed focusing device for microscope objective lens
MEMS Device Test Driver Platform
Fiber optic alignment coupling precision adjustment equipment
Material micro deformation testing system
Biological microscopy imaging scanning platform
Vacuum chamber piezoelectric actuator driving unit
Product Specifications
Output voltage -30V to 130V
Fixed voltage gain of 10 times
Number of channels: Three channels with independent output
The Physik E-503K004 high-voltage amplifier belongs to the PI piezoelectric power amplification module, which is used to amplify the low-voltage control signal and drive the piezoelectric ceramic actuator to achieve nanometer level high-precision displacement adjustment
