KLA Tencor 0052196-008模拟电路板

KLA-Tencor  0052196-008模拟电路板

1.产 品 资 料 介 绍：

中文资料：

KLA-Tencor 0052196-008 模拟电路板是应用于半导体晶圆检测设备中的关键电子模块，主要功能是对来自传感器和光学系统的模拟信号进行精密处理和放大，为后续的数据分析提供高保真信号支持。

主要应用领域如下：

1. 晶圆表面缺陷检测系统

此电路板被广泛集成于 KLA-Tencor 的 AIT UV 等晶圆检测设备中，处理来自光学传感器或扫描模块的模拟信号，用于检测：

• 微米级至纳米级颗粒

• 划痕、凹陷等物理缺陷

• 表面形貌异常

2. 光电信号处理

该板卡是模拟信号链中的关键一环，用于：

• 光电探测器（如CCD或光电二极管）的信号预处理

• 模拟放大、滤波

• 信号调理（以匹配ADC转换要求）

3. 高级图像采集系统

在图像采集通道中，该电路板可将弱小光学信号转换为稳定可用的电压信号，是高分辨率图像生成和对比分析的技术基础。

4. 工艺监控与质量控制

应用于前道晶圆制造的工艺控制流程中，如：

• 薄膜沉积检测

• 光刻掩模验证

• 蚀刻后轮廓检测

英文资料：

The KLA Tencor 0052196-008 analog circuit board is a key electronic module used in semiconductor wafer inspection equipment. Its main function is to precisely process and amplify analog signals from sensors and optical systems, providing high fidelity signal support for subsequent data analysis.

The main application areas are as follows:

1. Wafer surface defect detection system

This circuit board is widely integrated into KLA Tencor's AIT UV and other wafer inspection equipment, processing analog signals from optical sensors or scanning modules for detecting:

Micron to nanometer sized particles

Physical defects such as scratches and dents

Abnormal surface morphology

2. Optoelectronic signal processing

This board is a crucial link in the analog signal chain, used for:

Signal preprocessing of photodetectors (such as CCD or photodiodes)

Simulate amplification and filtering

Signal conditioning (to match ADC conversion requirements)

3. Advanced image acquisition system

In the image acquisition channel, this circuit board can convert weak optical signals into stable and usable voltage signals, which is the technical foundation for high-resolution image generation and comparative analysis.

4. Process monitoring and quality control

Applied in the process control flow of front-end wafer manufacturing, such as:

Thin film deposition detection

Photolithography mask verification

Outline detection after etching
