EATON PL9-C6-2-DC 微型断路器

 EATON  PL9-C6-2-DC 微型断路器

1.产 品 资 料 介 绍：

中文资料：

EATON PL9-C6-2-DC 微型断路器 是一款专为直流系统设计的双极微型断路器，适用于直流供电回路的过载和短路保护，常见于工业、通信和新能源领域。以下是其详细介绍：

一、产品基本信息

• 型号：PL9-C6-2-DC

• 类型：微型断路器（Miniature Circuit Breaker, MCB）

• 极数：2极（双极）

• 额定电流：6 A

• 额定工作电压：最高通常支持 220V DC（单极）或 440V DC（两极串联）

• 脱扣特性：C型脱扣曲线（适合中等感性负载）

• 安装方式：标准DIN导轨安装

• 认证标准：符合IEC/EN 60947-2或IEC/EN 60898（针对直流应用的要求）

二、产品特点

• 专为直流设计：断路器内部灭弧装置优化，适合直流电弧特性，确保快速安全断开直流回路。

• 双极断开：同时切断两个极，确保断路器在直流系统中的安全隔离。

• C型脱扣：允许适度的启动电流浪涌，适合直流电机、继电器等感性负载。

• 高分断能力：具备良好的短路保护能力，满足工业环境需求。

• 紧凑结构：设计适合现代配电箱和控制柜的空间要求，便于安装和维护。

英文资料：

EATON PL9-C6-2-DC miniature circuit breaker is a bipolar miniature circuit breaker designed specifically for DC systems, suitable for overload and short circuit protection of DC power supply circuits, commonly used in industrial, communication, and new energy fields. Here is a detailed introduction:

1、 Basic Product Information

Model: PL9-C6-2-DC

Type: Miniature Circuit Breaker (MCB)

Number of poles: 2 poles (bipolar)

Rated current: 6 A

Rated operating voltage: typically supports up to 220V DC (single pole) or 440V DC (two pole series)

Release characteristics: C-type release curve (suitable for moderate inductive loads)

Installation method: Standard DIN rail installation

Certification standard: Complies with IEC/EN 60947-2 or IEC/EN 60898 (requirements for DC applications)

2、 Product Features

Specially designed for DC: optimized internal arc extinguishing device of circuit breaker, suitable for DC arc characteristics, ensuring fast and safe disconnection of DC circuit.

Bipolar disconnection: Simultaneously disconnect both poles to ensure safe isolation of the circuit breaker in the DC system.

C-type trip: allows moderate starting current surge, suitable for inductive loads such as DC motors and relays.

High breaking capacity: It has good short-circuit protection capability and meets the needs of industrial environments.

Compact structure: Designed to meet the space requirements of modern distribution boxes and control cabinets, easy to install and maintain.

2.产      品      展      示
