EATON PL9-C10-2-DC 断路器
1.产 品 资 料 介 绍：
中文资料：
EATON PL9-C10-2-DC 微型断路器 是一款专为直流应用设计的双极微型断路器，广泛应用于直流配电系统中，提供过载和短路保护。以下是该型号的详细介绍：
一、产品基本信息
型号：PL9-C10-2-DC
类型：微型断路器（MCB）
极数：2极（双极）
额定电流：10 A
额定电压：最高通常支持220V DC（单极）或440V DC（两极串联）
脱扣曲线：C型（适合轻到中度感性负载）
安装方式：DIN导轨安装
标准认证：符合IEC/EN 60947-2及相关直流断路器标准
二、产品特点
专为直流回路设计，断路器内部灭弧系统优化，保证直流弧的安全快速熄灭。
双极断开，同时断开两极，确保直流供电系统的安全隔离。
C型脱扣曲线，适合电机、继电器等有启动浪涌的负载。
高分断能力，可承受较大短路电流。
紧凑设计，方便安装于标准配电箱和控制柜。
三、典型应用领域
工业自动化
直流控制柜与设备的电路保护
直流电机、继电器、传感器等负载的保护
新能源及光伏系统
光伏发电系统的直流侧保护
储能设备的直流电路安全防护
通信设备
通信基站-48V直流电源系统保护
数据中心直流电源分支保护
交通运输
轨道交通直流供电系统
电动汽车充电桩及相关直流设备保护
英文资料：
EATON PL9-C10-2-DC miniature circuit breaker is a bipolar miniature circuit breaker designed specifically for DC applications, widely used in DC distribution systems to provide overload and short-circuit protection. The following is a detailed introduction of the model:
1、 Basic Product Information
Model: PL9-C10-2-DC
Type: Miniature Circuit Breaker (MCB)
Number of poles: 2 poles (bipolar)
Rated current: 10A
Rated voltage: typically supports up to 220V DC (single pole) or 440V DC (two pole series)
Release curve: C-type (suitable for light to moderate inductive loads)
Installation method: DIN rail installation
Standard certification: Complies with IEC/EN 60947-2 and related DC circuit breaker standards
2、 Product Features
Specially designed for DC circuits, the internal arc extinguishing system of the circuit breaker is optimized to ensure safe and fast extinguishing of DC arcs.
Bipolar disconnection, while disconnecting both poles, ensures safe isolation of the DC power supply system.
C-type trip curve, suitable for loads with starting surges such as motors and relays.
High breaking capacity, capable of withstanding large short-circuit currents.
Compact design, easy to install in standard distribution boxes and control cabinets.
3、 Typical application areas
Industrial Automation
Circuit protection of DC control cabinet and equipment
Protection of DC motors, relays, sensors and other loads
New energy and photovoltaic systems
DC side protection of photovoltaic power generation system
DC circuit safety protection of energy storage equipment
communication devices
Communication base station -48V DC power system protection
DC power branch protection for data centers
Transportation
DC power supply system for rail transit
Protection of electric vehicle charging stations and related DC equipment
2.产 品 展 示
