EATON PL9-C16-2-DC 微型断路器
1.产 品 资 料 介 绍：
中文资料：
EATON PL9-C16-2-DC 微型断路器（直流用）
产品简介
EATON PL9-C16-2-DC 是伊顿公司生产的一款专用于直流电路保护的微型断路器，属于PL9系列。该断路器专为直流电系统设计，具备高效的过载和短路保护功能，适合太阳能光伏、电动车充电桩及电池储能等直流电力系统，能够保障设备及线路的安全运行。
主要技术参数
额定电流（In）：16安培
极数：2极
额定工作电压：直流系统专用（通常DC 250V或更高，具体需参照产品手册）
脱扣特性：C型曲线，瞬时脱扣
额定短路分断能力：符合国家及国际标准，能够承受高达数千安培的短路电流冲击
安装方式：导轨式安装，方便快速安装与拆卸
工作环境温度：适应多种工业环境，一般为 -25°C 至 +70°C
符合标准：符合IEC 60947-2和GB/T 16917.1等相关标准
产品特点
高可靠性保护：对过载和短路状况快速响应，有效保护下游设备不受损坏。
适应直流特性设计：断路器内部设计考虑了直流电弧的熄灭，确保断开能力和安全性能。
抗浪涌能力强：能承受电网中因雷击或开关操作产生的浪涌电流，减少误动作风险。
操作方便：带有明显的开关位置指示，支持手动和自动断开功能。
紧凑体积：节省安装空间，适合复杂配电柜及设备内部安装。
英文资料：
EATON PL9-C16-2-DC Miniature Circuit Breaker (DC)
Product Introduction
EATON PL9-C16-2-DC is a miniature circuit breaker produced by Eaton Corporation specifically for DC circuit protection, belonging to the PL9 series. This circuit breaker is designed specifically for DC power systems and has efficient overload and short circuit protection functions. It is suitable for DC power systems such as solar photovoltaics, electric vehicle charging stations, and battery energy storage, and can ensure the safe operation of equipment and lines.
Main technical parameters
Rated current (In): 16 amperes
Number of poles: 2 poles
Rated operating voltage: DC system specific (usually DC 250V or higher, please refer to the product manual for details)
Release characteristics: C-curve, instantaneous release
Rated short-circuit breaking capacity: compliant with national and international standards, capable of withstanding short-circuit current surges of up to several thousand amperes
Installation method: rail type installation, convenient and fast installation and disassembly
Working environment temperature: Suitable for various industrial environments, generally ranging from -25 ° C to+70 ° C
Compliant with standards: Compliant with relevant standards such as IEC 60947-2 and GB/T 16917.1
Product Features
High reliability protection: responds quickly to overload and short circuit conditions, effectively protecting downstream equipment from damage.
Design adapted to DC characteristics: The internal design of the circuit breaker takes into account the extinguishing of DC arcs, ensuring both breaking capacity and safety performance.
Strong surge resistance: able to withstand surge currents generated by lightning strikes or switch operations in the power grid, reducing the risk of misoperation.
Easy to operate: with obvious switch position indication, supporting manual and automatic disconnection functions.
Compact size: saves installation space and is suitable for installation inside complex distribution cabinets and equipment.
