EATON PL9-C20-2 微型断路器
1.产 品 资 料 介 绍：
中文资料：
产品概述
EATON PL9-C20-2是一款专为低压交流电路设计的微型断路器，属于Eaton PL9系列。它主要用于电路的过载和短路保护，确保电气设备和电路的安全运行。该断路器采用C型脱扣曲线，适用于一般的照明、插座及电动机保护，广泛应用于住宅、商业及工业领域。
主要技术参数
额定电流（In）：20安培
极数：2极
额定电压：230/400伏交流电（AC）
脱扣特性：C型脱扣曲线，瞬时脱扣，适合一般负载
额定短路分断能力：通常为6kA或10kA，具体需参照产品规格说明
安装方式：35mm标准导轨安装，便于快速安装和维护
符合标准：符合IEC/EN 60898-1标准，满足国际安全和性能要求
环境适应性：工作温度范围宽，适应多种安装环境
产品特点
高效保护：能够快速断开过载和短路电流，防止电路和设备损坏。
紧凑设计：节省配电箱空间，方便多模块安装。
操作简便：开关手柄直观，方便用户识别开关状态。
稳定性强：高质量制造保证长时间稳定运行。
多用途适用：适合多种负载类型，包括照明、插座及小功率电机。
英文资料：
product overview
EATON PL9-C20-2 is a miniature circuit breaker designed specifically for low-voltage AC circuits, belonging to the Eaton PL9 series. It is mainly used for overload and short circuit protection of circuits, ensuring the safe operation of electrical equipment and circuits. This circuit breaker adopts a C-type trip curve and is suitable for general lighting, socket, and motor protection. It is widely used in residential, commercial, and industrial fields.
Main technical parameters
Rated current (In): 20 amperes
Number of poles: 2 poles
Rated voltage: 230/400 volts alternating current (AC)
Release characteristics: C-type release curve, instantaneous release, suitable for general loads
Rated short-circuit breaking capacity: usually 6kA or 10kA, please refer to the product specifications for details
Installation method: 35mm standard guide rail installation, easy to install and maintain quickly
Compliant with standards: Compliant with IEC/EN 60898-1 standard, meeting international safety and performance requirements
Environmental adaptability: Wide working temperature range, suitable for various installation environments
Product Features
Efficient protection: able to quickly disconnect overload and short-circuit currents, preventing damage to circuits and equipment.
Compact design: saves distribution box space and facilitates multi module installation.
Easy to operate: The switch handle is intuitive, making it convenient for users to identify the switch status.
Strong stability: High quality manufacturing ensures long-term stable operation.
Multi purpose application: Suitable for various types of loads, including lighting, sockets, and low-power motors.
2.产 品 展 示
