Vibro-Meter MPC4 200-510-111-034 机械保护卡
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
Vibro-Meter MPC4 200-510-111-034 是 VM600 系列中专用于旋转机械（如汽轮机、压缩机、风机等）状态监测与保护的高性能模块。它可接收多个传感器输入信号，提供实时数据处理与报警功能，是机组安全运行的关键组件之一。
二、技术参数
| 项目 | 参数说明 |
|---|---|
| 产品型号 | MPC4 200-510-111-034 |
| 模块类型 | 4 通道机械保护卡 |
| 监测通道数 | 4 个独立通道（每通道可独立配置） |
| 支持信号类型 | IEPE 加速度计、速度传感器、涡流探头、位移传感器等 |
| 安装方式 | 插入式，适用于 VM600 架构 |
| 报警功能 | 支持预报警（Alert）与危险报警（Danger）两级限值设定 |
| 输出类型 | 继电器触点输出、模拟信号输出（4~20 mA） |
| 电源供电 | 由系统主架提供（24 V DC） |
| 工作温度范围 | -20°C ~ +65°C |
| 电气隔离 | 通道之间及输出接口电气隔离 |
| 标准认证 | 满足 API 670 要求（视系统配置） |
英文资料：
1、 Product Overview
Vibro Meter MPC4 200-510-111-034 is a high-performance module specifically designed for monitoring and protecting the status of rotating machinery (such as turbines, compressors, fans, etc.) in the VM600 series. It can receive multiple sensor input signals, provide real-time data processing and alarm functions, and is one of the key components for the safe operation of the unit.
2、 Technical parameters
Project parameter description
Product model MPC4 200-510-111-034
Module type 4-channel mechanical protection card
Number of monitoring channels: 4 independent channels (each channel can be independently configured)
Support signal types such as IEPE accelerometer, velocity sensor, eddy current probe, displacement sensor, etc
Installation method plug-in, suitable for VM600 architecture
The alarm function supports setting two levels of limit values: Alert and Danger
Output type: Relay contact output, analog signal output (4-20 mA)
The power supply is provided by the system main frame (24 V DC)
Working temperature range -20 ° C~+65 ° C
Electrical isolation between channels and output interfaces
Standard certification meets API 670 requirements (depending on system configuration)
2.产 品 展 示
