Vibro-Meter 200-570-101-015 RLC16-V111印刷电路板
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
Vibro-Meter 200-570-101-015 RLC16-V111 是一款用于机器状态监测和振动保护系统的 RLC16 系列印刷电路板（PCB）。它通常用于工业旋转设备的振动测量、报警、保护系统中，属于Vibro-Meter VM600系列或类似平台中的功能模块。
该板卡通过多个通道处理来自加速度计、速度传感器或位移探头的信号，并执行滤波、整形、测量与诊断等操作。
二、产品型号说明
产品名称：RLC16-V111 印刷电路板
订货号（P/N）：200-570-101-015
制造商：Vibro-Meter（属于 Meggitt Group）
模块系列：RLC16 系列（Relay Logic Card）
版本号：V111（表示该印刷电路板的硬件修订版本）
三、核心功能与技术特点
| 功能项目 | 描述 |
|---|---|
| 信号处理 | 可接收最多 16 通道的输入信号（通常为振动或位置传感器信号） |
| 逻辑控制功能 | 提供可编程的报警/跳闸逻辑功能，用于机器状态响应 |
| 继电器输出 | 配有可配置的继电器输出，用于报警信号或系统联锁 |
| 状态指示 | 提供 LED 指示器显示当前通道状态或故障报警 |
| 系统集成 | 可与 VM600 系列其他模块配合工作，如 MPC4、IOC4T、CPUM 等 |
| 自诊断功能 | 具备故障检测、模块运行监控、自诊断能力 |
| 配置方式 | 通过系统软件或机架跳线设置模块参数 |
| 热插拔支持 | 安装于标准 Vibro-Meter 机架中，支持带电更换（Hot Swap） |
英文资料：
1、 Product Overview
Vibro Meter 200-570-101-015 RLC16-V111 is an RLC16 series printed circuit board (PCB) used for machine condition monitoring and vibration protection systems. It is commonly used in vibration measurement, alarm, and protection systems for industrial rotating equipment, and is a functional module in the Vibro Meter VM600 series or similar platforms.
This board card processes signals from accelerometers, velocity sensors, or displacement probes through multiple channels and performs filtering, shaping, measurement, and diagnostic operations.
2、 Product Model Description
Product Name: RLC16-V111 Printed Circuit Board
Order number (P/N): 200-570-101-015
Manufacturer: Vibro Meter (belonging to Meggitt Group)
Module series: RLC16 series (Relay Logic Card)
Version number: V111 (indicating the hardware revision version of the printed circuit board)
3、 Core functions and technical features
Functional project description
Signal processing can receive up to 16 channels of input signals (usually vibration or position sensor signals)
The logic control function provides programmable alarm/trip logic function for machine status response
The relay output is equipped with configurable relay outputs for alarm signals or system interlocking
Status indication provides LED indicators to display the current channel status or fault alarm
System integration can work in conjunction with other modules in the VM600 series, such as MPC4, IOC4T, CPUM, etc
Self diagnostic function with fault detection, module operation monitoring, and self diagnostic capabilities
The configuration method is to set module parameters through system software or rack jumpers
Hot swappable supports installation in standard Vibro Meter racks and supports live replacement (Hot Swap)
