TEL Tokyo Electron 1381-650052-11电子连接板

TEL Tokyo Electron  1381-650052-11电子连接板

1.产 品 资 料 介 绍：

中文资料：

一、基本信息

• 产品型号：1381-650052-11

• 产品名称：电子连接板（Electronic Connector Board）

• 制造商：Tokyo Electron Ltd.（东京电子）

• 部件类别：信号连接接口板 / 通信中继板

• 适用设备：用于 Tokyo Electron 半导体制造设备内部

二、功能定位

1. 模块与模块之间的信号连接桥梁

   • 实现控制板、传感器、驱动单元之间的电子信号交互。

2. 物理接口统一与线路整理

   • 用于整理和管理复杂的设备内部信号线缆，提高模块间连接效率和可靠性。

3. 信号中继与分配功能

   • 对输入信号进行中继、分支、切换或分配，实现多方向传输。

4. 板间连接平台

   • 通常为插拔式接口板，用于将多个子系统通过标准接口整合为一个完整工作系统。

三、应用领域

• 半导体设备内部系统连接
  例如：

  • 等离子蚀刻设备（Etchers）

  • 化学气相沉积设备（CVD）

  • 晶圆清洗设备（Wafer Cleaners）

  • 真空输送单元或自动化搬送系统

• 设备主控制系统中的通信中枢
  协助信号板与控制板之间完成数据、命令和状态的高效交互。

四、技术特点（典型）

• 工业级 PCB 结构，适合洁净室与高可靠性设备

• 多针脚高速连接器设计，支持数字/模拟信号混合传输

• 插拔式安装，支持模块快速更换与维修

• 高电磁兼容性设计，抗干扰能力强

• 具备信号分隔区域，防止信号串扰或反射

英文资料：

1、 Basic Information

Product model: 1381-650052-11

Product Name: Electronic Connector Board

Manufacturer: Tokyo Electron Ltd

Component Category: Signal Connection Interface Board/Communication Relay Board

Applicable equipment: Used for the interior of Tokyo Electron semiconductor manufacturing equipment

2、 Functional positioning

Signal connection bridge between modules

Realize electronic signal interaction between the control board, sensors, and drive units.

Unified physical interface and line organization

Used for organizing and managing complex internal signal cables of devices, improving the efficiency and reliability of module connections.

Signal relay and distribution function

Relay, branch, switch or allocate input signals to achieve multi-directional transmission.

Inter board connection platform

Usually a plug-in interface board, used to integrate multiple subsystems into a complete working system through standard interfaces.

3、 Application Fields

Internal system connection of semiconductor equipment

For example:

Plasma etching equipment (Etchers)

Chemical Vapor Deposition Equipment (CVD)

Wafer Cleaners

Vacuum conveying unit or automated conveying system

Communication center in the main control system of the equipment

Assist in efficient interaction of data, commands, and status between the signal board and control board.

4、 Technical characteristics (typical)

Industrial grade PCB structure, suitable for cleanrooms and high reliability equipment

Multi pin high-speed connector design, supporting mixed transmission of digital/analog signals

Plug in installation, supporting quick module replacement and maintenance

High electromagnetic compatibility design, strong anti-interference ability

Equipped with signal separation areas to prevent signal crosstalk or reflection

2.产      品      展      示
