TEL Tokyo Electron 5044-000223-11接口模块

TEL Tokyo Electron  5044-000223-11接口模块

1.产 品 资 料 介 绍：

TEL Tokyo Electron 5044-000223-11 接口模块简介

一、基本信息

• 型号：5044‑000223‑11

• 别名：APC‑T0095A‑11 接口板（BOARD, CONN ADH CHEM #05）

• 制造商：Tokyo Electron Ltd.（TEL）

• 功能类别：接口连接板，负责模块之间信号与电源传递

二、功能描述

1. 信号桥接
   用于半导体设备内部各子系统（如化学供应系统、气体控制单元等）之间的信号连接和转发。

2. 电源分配
   提供电压和电流分配功能，用于支持连接的多个小模块或传感器。

3. 结构化连接
   采用标准化PCB板卡形式，通过背板或插槽插入主机架，实现模块化集成安装。

三、典型应用场景

• 广泛用于半导体设备中化学品供应或气体控制系统——“ADH CHEM #05”表明此板可能用于化学品泵或阀门的连接控制

• 常作为设备维护替换件使用，适用于模块化维修和扩展

• 配合TEL控制主机架（如Trias, Alpha系列等）中的I/O部分进行集成

英文资料：

Introduction to TEL Tokyo Electron 5044-000223-11 Interface Module

1、 Basic Information

Model: 5044-000223-11

Alias: APC-T0095A-11 Interface Board (BOARD, CONN ADH CHEM # 05)

Manufacturer: Tokyo Electron Ltd. (TEL)

Function category: Interface connection board, responsible for signal and power transmission between modules

2、 Function Description

Signal bridging

Used for signal connection and forwarding between various subsystems within semiconductor equipment, such as chemical supply systems, gas control units, etc.

power distribution

Provide voltage and current distribution functions to support the connection of multiple small modules or sensors.

Structured connection

Adopting standardized PCB board form, modular integrated installation is achieved by inserting the motherboard through the backplane or slot.

3、 Typical application scenarios

Widely used in chemical supply or gas control systems in semiconductor equipment - "ADH CHEM # 05" indicates that this board may be used for connection control of chemical pumps or valves

Often used as equipment maintenance replacement parts, suitable for modular maintenance and expansion

Integrate the I/O part of TEL control host racks (such as Trias, Alpha series, etc.)
