TEL Tokyo Electron 1B80-002393-12附加板

TEL Tokyo Electron  1B80-002393-12附加板

1.产 品 资 料 介 绍：

产品名称：

TEL Tokyo Electron 1B80-002393-12 附加板
（Add-on Board / Auxiliary PCB）

产品功能简介：

该附加板是 Tokyo Electron（TEL）半导体设备中用于功能扩展或特定信号处理的辅助电路板。通常作为主控系统、接口板或通信模块的扩展单元，具备以下功能：

• 提供额外的 I/O 通道或控制逻辑

• 扩展原有系统的功能，如多点采集、额外驱动或通信端口

• 接收和调理来自传感器或子模块的信号

• 实现逻辑判断、缓冲、电平转换或隔离等辅助功能

• 可与主板、控制卡、通信板等通过排针、排线或底座互联

主要应用领域：

1. 信号采集与调理扩展

• 用于采集多个外部传感器或控制点信号

• 对输入信号进行滤波、隔离、缓冲等处理，确保信号稳定性

2. 控制输出扩展

• 扩展执行器控制通道，如电磁阀、电机、加热器等控制信号输出

• 支持高/低电平驱动，部分型号具备继电器输出功能

3. 主控板功能增强

• 与主控制板协同运行，执行特定子逻辑或支持更多功能选项

• 增强系统兼容性或适应定制工艺需求

4. 通信与接口增强

• 提供额外串口（如 RS-232、RS-485）、CAN、I²C、SPI 等通信接口

• 支持与外部测试仪、上位机或分布式模块通信

英文资料：

TEL Tokyo Electron 1B80-002393-12 Additional Board

（Add-on Board / Auxiliary PCB）

Product Function Introduction:

This additional board is an auxiliary circuit board used for functional expansion or specific signal processing in Tokyo Electron (TEL) semiconductor equipment. Usually used as an expansion unit for the main control system, interface board, or communication module, it has the following functions:

Provide additional I/O channels or control logic

Expand the functionality of the existing system, such as multi-point acquisition, additional drivers, or communication ports

Receive and condition signals from sensors or submodules

Implement auxiliary functions such as logical judgment, buffering, level conversion, or isolation

Can be interconnected with motherboards, control cards, communication boards, etc. through pin headers, cables, or bases

Main application areas:

1. Signal acquisition and conditioning expansion

Used to collect signals from multiple external sensors or control points

Filter, isolate, and buffer the input signal to ensure signal stability

2. Control output expansion

Expand the control channels of actuators, such as solenoid valves, motors, heaters, and other control signal outputs

Supports high/low level driving, some models have relay output function

3. Enhanced functionality of the main control board

Collaborate with the main control board to execute specific sub logic or support more functional options

Enhance system compatibility or adapt to customized process requirements

4. Communication and interface enhancement

Provide additional communication interfaces such as RS-232, RS-485, CAN, I ² C, SPI, etc

Support communication with external testers, upper computers, or distributed modules

2.产      品      展      示
