KEBA E-3-ACU-10主控板卡
1.产 品 资 料 介 绍：
KEBA E-3-ACU-10 是 KEBA 自动化系统中的一款核心 主控板卡（ACU = Axis Control Unit），用于高速实时控制工业设备的运动与逻辑功能。该控制单元专为对精度和响应速度要求较高的场合设计，常应用于注塑、包装、机器人等机械设备的伺服控制系统中。其具备强大的轴控制、总线通信和处理能力，是模块化控制系统中的关键组件。
技术参数
产品名称：E-3-ACU-10 主控板卡
类型：运动控制主板（Axis Controller Unit）
处理器：高性能工业CPU，适用于多任务控制
控制轴数：支持多轴伺服电机控制（通常为4~8轴）
总线接口：支持 EtherCAT、CANopen、KEBA KeConnect 等现场总线协议
扩展性：可通过扩展模块（I/O、温度、模拟量等）实现系统拓展
兼容系统：KEBA KeMotion、KePlast、KeTop 等自动化控制平台
安装方式：插槽式模块化安装
冷却方式：自然风冷或系统级冷却
电源要求：24V DC 输入
应用场景
注塑成型机系统
控制合模、注射、顶出等多个运动轴
实现高精度同步与压力/位置曲线控制
包装设备
对送膜轴、封口轴等进行高速同步控制
实现高效、低误差的动态动作流程
机器人系统（如机械臂）
进行多轴协同运动控制，路径规划
支持实时位置反馈与运动曲线插补
数控自动化生产线
应用于柔性自动装配、自动上下料系统
控制多轴传动与设备间联动逻辑
印刷和纺织机械
控制主轴和辅助轴，实现同步走布或卷绕控制
英文资料：
KEBA E-3-ACU-10 is a core control board (ACU=Axis Control Unit) in KEBA automation systems, used for high-speed real-time control of motion and logic functions of industrial equipment. This control unit is designed for applications that require high precision and response speed, and is commonly used in servo control systems for mechanical equipment such as injection molding, packaging, and robots. It has powerful axis control, bus communication, and processing capabilities, and is a key component in modular control systems.
Technical Parameter
Product Name: E-3-ACU-10 Controller Board
Type: Axis Controller Unit
Processor: High performance industrial CPU, suitable for multitasking control
Number of control axes: Supports multi axis servo motor control (usually 4-8 axes)
Bus interface: Supports fieldbus protocols such as EtherCAT, CANopen, KEBA KeConnect, etc
Scalability: System expansion can be achieved through expansion modules (I/O, temperature, analog, etc.)
Compatible systems: KEBA KeMotion, KePlast, KeTop and other automation control platforms
Installation method: slot type modular installation
Cooling method: natural air cooling or system level cooling
Power requirement: 24V DC input
Application scenarios
Injection molding machine system
Control multiple motion axes such as mold closing, injection, and ejection
Realize high-precision synchronization and pressure/position curve control
Packaging Equipment
High speed synchronous control of film feeding shaft, sealing shaft, etc
Realize efficient and low error dynamic action flow
Robot systems (such as robotic arms)
Perform multi axis collaborative motion control and path planning
Support real-time position feedback and motion curve interpolation
CNC automated production line
Applied to flexible automatic assembly and automatic loading and unloading systems
Control the linkage logic between multi axis transmission and equipment
Printing and textile machinery
Control the main and auxiliary axes to achieve synchronous feeding or winding control
2.产 品 展 示
