KEBA E-FLOPPY电路板

 KEBA E-FLOPPY电路板

1.产 品 资 料 介 绍：

KEBA E-FLOPPY 电路板是一款用于 KEBA 自动化控制系统中的软驱接口板（Floppy Interface Board），主要用于提供与软盘驱动器的连接功能。该模块在早期自动化系统或工业控制设备中，用于程序、参数、配方数据的存储与加载，尤其适用于不具备现代USB或以太网接口的旧款控制系统。

技术参数

• 产品名称：E-FLOPPY

• 功能类型：软盘驱动器控制与接口电路板

• 兼容驱动器类型：3.5英寸软盘驱动器（FDD，Floppy Disk Drive）

• 接口类型：34针软驱标准接口 + 控制逻辑接口

• 适用系统：KEBA早期控制系统或基于E系列主控平台的设备

• 电源要求：通常为 5V DC（来自主控系统）

• 安装方式：模块化插板式或面板内嵌安装

• 传输速率：符合FDD标准，约250kbps（取决于控制器）

应用场景

1. 老式注塑机或控制台

   • 用于从软盘中加载工艺参数、工厂设置或程序数据

   • 配合KEBA主控卡对旧设备进行软件更新或数据备份

2. 早期工业自动化设备

   • 包括印刷、包装、纺织等机台的文件数据传输

   • 在无网络支持的环境中，作为主要数据载体接口

3. 系统维护与故障诊断

   • 工程师通过软盘读取系统日志或下载系统配置

   • 便于远程或离线的维护与恢复操作

4. OEM设备集成

   • 一些定制设备中使用 E-FLOPPY 作为持久化存储接口

   • 配合KEBA面板、键盘及控制器构建独立控制系统

英文资料：

The KEBA E-FLOPPY circuit board is a Floppy Interface Board used in KEBA automation control systems, primarily for providing connectivity to floppy disk drives. This module was used in early automation systems or industrial control equipment for storing and loading programs, parameters, and recipe data, especially for older control systems that do not have modern USB or Ethernet interfaces.

Technical Parameter

Product Name: E-FLOPPY

Function type: Floppy drive control and interface circuit board

Compatible drive type: 3.5-inch floppy disk drive (FDD, Floppy Disk Drive)

Interface type: 34 pin floppy drive standard interface+control logic interface

Applicable system: KEBA early control system or equipment based on E-series main control platform

Power requirement: Typically 5V DC (from the main control system)

Installation method: Modular plug-in or panel embedded installation

Transmission rate: Complies with FDD standards, approximately 250kbps (depending on the controller)

Application scenarios

Old style injection molding machine or console

Used to load process parameters, factory settings, or program data from floppy disks

Cooperate with KEBA main control card to ｕｐｄａｔｅ software or backup data for old devices

Early industrial automation equipment

File data transmission for printing, packaging, textile and other machinery

As the primary data carrier interface in an environment without network support

System maintenance and fault diagnosis

Engineers read system logs or download system configurations through floppy disks

Convenient for remote or offline maintenance and recovery operations

OEM equipment integration

E-FLOPPY is used as a persistent storage interface in some customized devices

Build an independent control system in conjunction with KEBA panel, keyboard, and controller

2.产      品      展      示
