Atlas Copco PF3009-C-HW电源焦点传感器
1.产 品 资 料 介 绍：
一、一、产品概述
Atlas Copco PF3009-C-HW 是 PF3000 系列中一款高端配置的 电动拧紧控制器，其主要功能是控制电动工具的扭矩和角度，同时集成电源供应、拧紧程序控制、焦点识别、过程监控与数据通讯等功能。
“C”代表标准控制版本，适用于中高复杂度装配需求；该型号一般搭配 Tensor ST/ES/ETX 系列工具，作为精密拧紧系统的核心控制单元，广泛应用于自动化装配线。
注：术语中提到的“焦点传感器”并非独立传感器，而是指控制器在焦点控制（Focus Tightening Point）中的功能，即针对特定拧紧点进行高精度数据识别与过程控制。
二、技术参数（简要）
输入电源：100–240V AC，50/60Hz
控制方式：扭矩控制、角度控制、多阶段控制、拧紧窗口管理
支持工具：Tensor ST、ETX、ES 系列等
通信接口：以太网、I/O、RS232，支持扩展（如 ProfiBus、DeviceNet）
程序管理：支持多组拧紧程序切换，适应混流生产
安装方式：控制柜或工作站集成式安装
三、应用领域
1. 汽车总装车间
发动机、变速箱、转向系统等关键部件螺栓拧紧
底盘与车身模块连接，尤其适用于安全等级高、容错要求严格的工序
拧紧结果与 VIN 码绑定，实现装配追溯
2. 新能源汽车与电池制造
电池模组外壳、液冷板、电气连接部位的精密拧紧
电驱系统控制器、电源转换模块中的紧固连接件
焦点控制技术提升电池安全螺栓的一致性和可靠性
3. 重型机械与轨道交通
火车车厢、刹车模块、底盘部件中高强度螺丝连接控制
需过程曲线记录的关键连接部位，如桥梁支架、液压系统等
4. 高端电子制造
服务器、电控箱、变频器等的外壳及内部结构件装配
特别适合塑料和金属混合结构的微扭矩拧紧工序
5. 自动化生产线系统
与机器人、PLC 协作完成自动拧紧任务
支持智能识别当前工位或产品型号，切换相应程序
通过“焦点控制”提高自动化生产过程中的稳定性
英文资料：
1、 1. Product Overview
Atlas Copco PF3009-C-HW is a high-end electric tightening controller in the PF3000 series. Its main function is to control the torque and angle of electric tools, while integrating functions such as power supply, tightening program control, focus recognition, process monitoring, and data communication.
C "represents the standard control version, suitable for medium to high complexity assembly requirements; This model is generally paired with Tensor ST/ES/ETX series tools as the core control unit of precision tightening systems and is widely used in automated assembly lines.
Note: The term "focus sensor" referred to in the terminology is not an independent sensor, but rather the function of the controller in focus tightening point control, which is to perform high-precision data recognition and process control for specific tightening points.
2、 Technical parameters (brief)
Input power supply: 100-240V AC, 50/60Hz
Control methods: torque control, angle control, multi-stage control, tightening window management
Supporting tools: Tensor ST, ETX, ES series, etc
Communication interface: Ethernet I/O、RS232， Support extensions (such as ProfiBus, DeviceNet)
Program management: Supports switching between multiple tightening programs to adapt to mixed flow production
Installation method: Integrated installation of control cabinet or workstation
3、 Application Fields
1. Automotive assembly workshop
Tightening of bolts for key components such as engine, gearbox, and steering system
Chassis and body module connection, especially suitable for processes with high safety levels and strict fault tolerance requirements
Bind the tightening result with the VIN code to achieve assembly traceability
2. New energy vehicles and battery manufacturing
Precise tightening of battery module casing, liquid cooling plate, and electrical connection parts
Tightening connectors in the electric drive system controller and power conversion module
Focus control technology enhances the consistency and reliability of battery safety bolts
3. Heavy Machinery and Rail Transit
High strength screw connection control in train carriages, brake modules, and chassis components
Key connection parts that require process curve recording, such as bridge supports, hydraulic systems, etc
4. High end electronic manufacturing
Assembly of shell and internal structural components of servers, electrical control boxes, frequency converters, etc
Specially suitable for micro torque tightening process of plastic and metal hybrid structures
5. Automated production line system
Collaborate with robots and PLCs to complete automatic tightening tasks
Support intelligent recognition of the current workstation or product model, and switch to the corresponding program
Improving stability in automated production processes through 'focus control'
