KJ4003X1-BB1垂直托架

KJ4003X1-BB1垂直托架

1.产 品 资 料 介 绍：

产品特点

1. 采用右侧 8 宽标准设计，可与左侧 KJ4003X1-BA1 配对使用，组成对称垂直 I/O 阵列，适配多种机柜布局。
2. 搭载 VerticalPLUS 专用架构，遵循规范断电插拔流程，提升系统维护与更换效率。
3. 配置双路供电，提供 12.6 VDC/15A 本地总线电源与 30 VDC/13A 现场回路电源，满足模块及现场仪表供电。
4. 具备 ATEX、FM 防爆认证，可应用于 Zone 2/Class I Div 2 危险工业场所。
5. 工作温度范围 - 40°C 至 + 70°C，适应极端高低温工业现场环境。
6. 满足严苛抗振动、抗冲击标准，可稳定运行于存在机械扰动的设备周边。
7. 支持 5%–95% 非冷凝湿度环境，IP20 防护等级，适配潮湿无淋水的工业场景。
8. 符合 ISA-S71.04 G3 污染等级，抵御粉尘、油污等工业污染物侵蚀。
9. 与 LocalBus 扩展器组合后总线总长不超 6.5 米，保障信号传输稳定。
10. 整机无用户可维修部件，密封结构减少维护操作与故障风险。
11. 兼容 DeltaV 全系列 I/O 模块及 KJ4006 系列端子排，支持标准与 SIS I/O 混合安装。
12. 跨柜体连接需采用导管布线，有效降低电磁干扰与物理损伤。
13. 托架空位需安装 KJ4001X1-FA1 盖板，保障整体结构与防护完整性。
14. 原厂生产，带完整序列号与产品信息标签，提供标准质保服务。
15. 垂直安装结构优化机柜空间利用率，适合老旧 DCS 系统升级改造。

结尾

KJ4003X1-BB1垂直托架  英文资料：

KJ4003X1-BB1 is a right side 8-slot VerticalPLUS vertical I/O bracket specifically designed for Emerson DeltaV distributed control systems. It is used for high-density installation of I/O modules in industrial automation scenarios, achieving stable connection between fieldbus and system host. It supports compliant deployment in hazardous areas and is suitable for process industry DCS system expansion and transformation.

Product Features

Adopting the standard design of 8-width on the right side, it can be paired with KJ4003X1-BA1 on the left side to form a symmetrical vertical I/O array, suitable for various cabinet layouts.

Equipped with VerticalPLUS dedicated architecture, following the standard power-off plugging process, improving system maintenance and replacement efficiency.

Configure dual power supply, providing 12.6 VDC/15A local bus power and 30 VDC/13A field circuit power to meet module and field instrument power supply needs.

Equipped with ATEX and FM explosion-proof certifications, it can be applied to Zone 2/Class I Div 2 hazardous industrial sites.

Working temperature range -40 ° C to+70 ° C, suitable for extreme high and low temperature industrial site environments.

Meet strict anti vibration and anti impact standards, and can operate stably around equipment with mechanical disturbances.

Supports non condensing humidity environments ranging from 5% to 95%, with an IP20 protection level, suitable for humid industrial environments without water spray.

Compliant with ISA-S71.04 G3 pollution level, resistant to industrial pollutants such as dust and oil pollution erosion.

Combined with LocalBus extender, the total length of the bus does not exceed 6.5 meters, ensuring stable signal transmission.

The whole machine has no user repairable parts, and the sealed structure reduces maintenance operations and the risk of malfunctions.

Compatible with the entire range of DeltaV I/O modules and KJ4006 series terminal blocks, supporting mixed installation of standard and SIS I/O.

Cross cabinet connections require conduit wiring to effectively reduce electromagnetic interference and physical damage.

The empty space of the bracket needs to be equipped with KJ4001X1-FA1 cover plate to ensure the integrity of the overall structure and protection.

Produced by the original factory, with complete serial numbers and product information labels, providing standard warranty services.

Vertical installation structure optimizes cabinet space utilization and is suitable for upgrading and renovating old DCS systems.

ending

KJ4003X1-BB1 is widely used in process industries such as petrochemical, power, coal chemical, and papermaking due to its stable electrical performance, compliance with explosion-proof certification, and strong environmental adaptability. Installation and commissioning must strictly follow the DeltaV hardware manual and hazardous area specifications to ensure long-term safe and stable operation of the system.

KJ4003X1-BB1垂直托架 产品展示
