1.产 品 资 料 介 绍：
产品特点
- 额定功率 600W，三相输入额定电流 20A，满足多轴伺服供电需求。
- 三相输入电压 400–480V AC，自适应 50/60Hz 工业电网。
- 内置 ESC 安全控制单元，支持急停、安全门、制动链冗余监控。
- 具备过压、欠压、过流、短路、过热、制动电阻过热多重保护。
- 集成轴制动控制回路，支持多轴抱闸与安全释放。
- 自带 24V DC 稳压输出，为控制器、I/O、编码器供电。
- 集成电池备份回路，保障断电后机器人位置数据不丢失。
- 实时监测内部温度、母线电压、制动电阻温度等参数。
- 面板 LED 指示灯，直观显示运行、待机、故障、安全状态。
- 采用螺丝端子接线，主回路与控制信号接口规范可靠。
- 防护等级 IP20，强制风冷散热，适合柜内安装。
- 通过 CE、UL、RoHS 认证，符合工业电气安全标准。
- 模块化结构，部件标准化，便于快速维护与更换。
- EMC 优化设计，抗干扰能力强，适应恶劣工业环境。
- 与 KUKA KRC2、KRC4 控制器及对应机器人机型高度兼容。
关键参数
- 工作温度：0–50℃，50–60℃降额使用
- 冷却方式：内置风扇强制风冷
- 安装方式：控制柜内面板或 DIN 导轨安装
- 适用场景：汽车制造、3C、金属加工、物流等自动化产线
结尾
KPS-600/20-ESC电源供应模块 英文资料：
KPS-600/20-ESC is a specialized servo power module for KUKA robots, mainly used in KRC2 and KRC4 control cabinets to provide stable power supply and safety logic control for servo axes, control systems, and safety circuits. It is the core component of robot power and safety.
Product Features
Rated power of 600W, three-phase input rated current of 20A, meeting the requirements of multi axis servo power supply.
Three phase input voltage of 400-480V AC, adaptive to 50/60Hz industrial power grid.
Built in ESC safety control unit, supporting emergency stop, safety door, and redundant monitoring of brake chain.
It has multiple protections for overvoltage, undervoltage, overcurrent, short circuit, overheating, and overheating of braking resistors.
Integrated axle brake control circuit, supporting multi axle brake and safety release.
Equipped with a 24V DC stabilized output for the controller I/O、 Encoder power supply.
Integrated battery backup circuit ensures that robot position data is not lost after power failure.
Real time monitoring of internal temperature, bus voltage, brake resistor temperature and other parameters.
The panel LED indicator light intuitively displays the running, standby, fault, and safety status.
Using screw terminals for wiring, the main circuit and control signal interface are standardized and reliable.
Protection level IP20, forced air cooling for heat dissipation, suitable for installation inside cabinets.
Certified by CE, UL, and RoHS, in compliance with industrial electrical safety standards.
Modular structure, standardized components, easy to maintain and ｒｅｐｌａｃｅ quickly.
EMC optimized design, strong anti-interference ability, suitable for harsh industrial environments.
Highly compatible with KUKA KRC2, KRC4 controllers and corresponding robot models.
key parameters
Working temperature: 0-50 ℃, 50-60 ℃ for derating use
Cooling method: built-in fan forced air cooling
Installation method: Control cabinet panel or DIN rail installation
Applicable scenarios: Automotive manufacturing, 3C, metal processing, logistics and other automated production lines
ending
KPS-600/20-ESC integrates power supply, braking, and safety monitoring, with high stability and strong adaptability. It is a key power module for the reliable operation of KUKA robots, and replacement and debugging must follow the original factory specifications of the equipment.
KPS-600/20-ESC电源供应模块 产品展示
