Silicon Graphics 040-1056-001 I/O 背板
1.产 品 资 料 介 绍：
- 型号：040-1056-001（SGI 原厂 I/O 背板）
- 功能定位：系统 I/O 信号、电源、扩展总线的互联背板
- 适配机型：多用于 SGI Octane、Onyx、Origin 系列机箱
- 背板类型：中置 / 后置 I/O 背板，连接主板、电源、I/O 面板
- 总线支持：兼容 XIO、PCI、GIO32 等 SGI 专属 / 标准总线
- 接口定义：板载专用连接器，对接主板、电源模块、I/O 子板
- 信号完整性：多层 PCB、阻抗控制，低串扰、低抖动
- 电源分配：集成大电流走线，分配多路 DC 供电（3.3V/5V/12V）
- 扩展能力：提供多个插槽 / 接口，支持 I/O 子卡、图形卡互联
- 材质工艺：工业级 FR-4 板材，抗氧化金手指，长期运行稳定
- 防护设计：过流 / 过压防护布局，防静电接地设计
- 机箱适配：标准 SGI 机箱尺寸，螺丝固定、即插即用
- 系统兼容：适配 IRIX 系统，与原厂主板 / 电源 / 配件完全匹配
- 用途：整机装配、老旧设备维修替换、背板故障更换
- 原厂品质：原装拆机 / 全新备件，兼容性强、故障率低
Silicon Graphics 040-1056-001 I/O 背板 产品英文
Silicon Graphics 040-1056-001 is an SGI original I/O backplane used for signal and power interconnection within the chassis. It is the core backplane component for multiple mid to high end SGI workstations/servers.
Model: 040-1056-001 (SGI original I/O backplane)
Functional positioning: Interconnection backplane for system I/O signals, power supply, and expansion bus
Compatible models: mostly used for SGI Octane, Onyx, Origin series chassis
Backboard type: mid/rear I/O backplane, connected to motherboard, power supply, and I/O panel
Bus support: compatible with SGI exclusive/standard buses such as XIO, PCI, GIO32, etc
Interface definition: Onboard dedicated connector, designed to interface with motherboards, power modules, and I/O daughter boards
Signal integrity: multi-layer PCB, impedance control, low crosstalk, low jitter
Power distribution: Integrated high current wiring, distributed multiple DC power supplies (3.3V/5V/12V)
Scalability: Provides multiple slots/interfaces, supports I/O daughter card and graphics card interconnection
Material and process: Industrial grade FR-4 board, anti-oxidation gold finger, stable long-term operation
Protection design: overcurrent/overvoltage protection layout, anti-static grounding design
Chassis adaptation: Standard SGI chassis size, screw fixed, plug and play
System compatibility: compatible with IRIX system, fully matched with original motherboard/power supply/accessories
Purpose: Whole machine assembly, maintenance and replacement of old equipment, replacement of backplate faults
Original factory quality: original disassembly/brand new spare parts, strong compatibility, low failure rate
Silicon Graphics 040-1056-001 I/O 背板 产品展示
