1.产 品 资 料 介 绍：
- 型号：CBOP 2546，Ansaldo 原装数据记录卡
- 核心功能：可编程采集 + 高速记录 + 掉电保存 + 远程上传
- 处理器：搭载工业级 MCU，支持C 语言 / 梯形图可编程
- 采集通道：多路模拟量 / 数字量，含热电偶、4–20mA、0–10V、干接点
- 采样精度：16 位 ADC，采样率可调（最高 100kHz）
- 存储容量：板载非易失性 FRAM/Flash，支持扩展 SD 卡
- 记录模式：连续 / 触发 / 定时记录，支持事件标记、断点续存
- 通讯接口：RS232/485、CAN、以太网，适配工业总线
- 编程环境：配套安萨尔多专用软件，参数组态、逻辑编写、数据导出
- 宽温运行：-25℃～+75℃，适应严苛工业现场
- 抗干扰：光电隔离、EMC 防护、浪涌抑制
- 抗震防潮：加固 PCB、涂层防护，适配振动 / 潮湿环境
- 供电：24VDC±20%，反接 / 过压 / 过流保护
- 尺寸：标准 3U/6U 板卡，适配 Ansaldo 机架
- 系统兼容：适配 Ansaldo SISTEMI、传动控制、能源管理系统
Ansaldo CBOP 2546 可编程数据记录卡 产品英文
Ansaldo CBOP 2546 Programmable Data Recording Card is a dedicated data acquisition and recording board for Ansaldo industrial control systems. It focuses on programmable, highly reliable, and long-term data recording, and is suitable for rail transit, power transmission, and industrial automation scenarios.
Model: CBOP 2546, Ansaldo original data recording card
Core functions: Programmable data acquisition+High speed recording+Power failure saving+Remote uploading
Processor: Equipped with industrial grade MCU, supporting C language/ladder diagram programming
Acquisition channel: Multiple analog/digital signals, including thermocouples, 4-20mA, 0-10V, dry contacts
Sampling accuracy: 16 bit ADC, adjustable sampling rate (up to 100kHz)
Storage capacity: onboard non-volatile FRAM/Flash, supporting expansion of SD card
Recording mode: continuous/triggered/timed recording, supporting event tagging and breakpoint continuation
Communication interface: RS232/485, CAN, Ethernet, compatible with industrial bus
Programming environment: equipped with Ansaldo dedicated software, parameter configuration, logic writing, data export
Wide temperature operation: -25 ℃~+75 ℃, suitable for harsh industrial sites
Anti interference: photoelectric isolation, EMC protection, surge suppression
Seismic and moisture-proof: reinforced PCB, coated protection, suitable for vibration/humid environments
Power supply: 24VDC ± 20%, reverse/overvoltage/overcurrent protection
Size: Standard 3U/6U card, compatible with Ansaldo rack
System compatibility: compatible with Ansaldo SISTEMI, transmission control, and energy management systems
Ansaldo CBOP 2546 可编程数据记录卡 产品展示
