140EHC20200计数器模块

1.产 品 资 料 介 绍：

140EHC20200 计数器模块

1. 原装工业级模块，双独立通道，最高500kHz计数频率。
2. 32 位计数分辨率，支持单相、正交 A/B 相、脉冲 + 方向等模式。
3. 输入兼容 5V TTL 与 RS-422 差分，适配多种编码器与传感器。
4. 集成 4 路 FET 输出，每路 0.5A，可直接驱动负载或触发信号。
5. 通道与总线间1780Vrms 隔离，抗干扰强，适配恶劣工况。
6. 可配置滤波（100ns–10μs），抑制信号抖动，计数稳定。
7. 支持比较匹配中断与索引脉冲捕获，响应实时性高。
8. 宽温运行（0°C–+60°C），适应高温、潮湿、粉尘环境。
9. 标准 140 机架安装，占 2 槽，拆装便捷，维护简单。
10. 低功耗设计（约 2.5W），背板供电，长期运行可靠。
11. 故障自诊断，支持断线、短路保护，降低停机风险。
12. 结构紧凑坚固，抗震耐冲击，工业现场耐用性强。
13. 支持增量 / 正交输入，适配编码器、流量计、接近开关。
14. 内置阈值配置（5V/12V/24V），传感器兼容性广。
15. 广泛用于机床、包装、纺织、冶金等高速精控系统。140EHC20200 高速精准、隔离可靠，是工业自动化高频计数与运动控制的核心模块。

140EHC20200计数器模块  产品英文

140EHC20200 counter module

140EHC20200 is a Schneider Quantum series high-speed counter module designed specifically for high-frequency pulse acquisition and precise counting, suitable for motion control, speed measurement, and position feedback scenarios.

Original industrial grade module, dual independent channels, maximum counting frequency of 500kHz.

32-bit counting resolution, supporting single-phase, orthogonal A/B phase, pulse+direction and other modes.

Input compatible with 5V TTL and RS-422 differential, compatible with various encoders and sensors.

Integrate 4 FET outputs, each with 0.5A, which can directly drive loads or trigger signals.

1780Vrms isolation between channel and bus, strong anti-interference, suitable for harsh working conditions.

Configurable filtering (100ns – 10 μ s) to suppress signal jitter and ensure stable counting.

Support matching interrupt and index pulse capture, with high real-time response.

Wide temperature operation (0 ° C -+60 ° C), suitable for high temperature, humidity, and dusty environments.

Standard 140 rack installation, occupying 2 slots, easy to disassemble and maintain.

Low power design (approximately 2.5W), backplane power supply, reliable long-term operation.

Fault self diagnosis, supporting wire breakage and short circuit protection, reducing the risk of shutdown.

Compact and sturdy structure, earthquake and impact resistance, strong durability in industrial sites.

Supports incremental/orthogonal input, compatible with encoders, flow meters, and proximity switches.

Built in threshold configuration (5V/12V/24V), with wide sensor compatibility.

Widely used in high-speed precision control systems such as machine tools, packaging, textiles, metallurgy, etc.

140EHC20200 is a core module for high-frequency counting and motion control in industrial automation, with high speed precision and reliable isolation.
