WOODWARD 5464-658数字速度传感器
1.产 品 资 料 介 绍：
中文资料：
WOODWARD 5464-658 数字速度传感器 是一款专为工业发动机控制系统设计的高性能速度检测装置，主要用于为 WOODWARD 控制器（如 EPG、2301A/Digital 系列、723、505、easYgen 等）提供精确的转速反馈信号，保障系统调速、同步和保护功能的正常运行。
一、产品概述
型号：WOODWARD 5464-658
类型：数字速度传感器（Digital Speed Sensor）
应用领域：大型柴油发电机、燃气发动机、水轮机、汽轮机等动力设备的转速检测
二、主要功能
高精度转速测量：提供脉冲信号反馈，支持高分辨率的 RPM 检测
数字信号输出：与 WOODWARD 控制器兼容，通常以 TTL、差分或频率信号方式输出
抗干扰能力强：适用于工业电磁环境，具有良好的抗噪设计
高可靠性：可长期稳定运行于高温、高湿、高振动环境
三、技术参数（典型，具体以型号数据表为准）
| 参数 | 说明 |
|---|---|
| 输入电源 | 通常为 8～32 VDC（由控制器供电） |
| 输出信号 | 脉冲输出（数字频率信号，TTL 或差分方波） |
| 测速范围 | 0～20,000 RPM（依传感器安装位置与齿轮齿数而定） |
| 检测对象 | 磁性齿轮或编码盘（通常需配合磁钢齿轮） |
| 安装接口 | 螺纹型或法兰型（根据版本） |
| 工作温度 | -40°C ～ +105°C（工业级） |
| 防护等级 | IP65 或以上（取决于外壳密封结构） |
英文资料：
The WOODWARD 5464-658 digital speed sensor is a high-performance speed detection device designed specifically for industrial engine control systems. It is mainly used to provide accurate speed feedback signals for WOODWARD controllers (such as EPG, 2301A/Digital series, 723, 505, easyYgen, etc.), ensuring the normal operation of system speed regulation, synchronization, and protection functions.
1、 Product Overview
Model: WOODWARD 5464-658
Type: Digital Speed Sensor
Application areas: Speed detection of power equipment such as large diesel generators, gas engines, water turbines, steam turbines, etc
2、 Main functions
High precision speed measurement: Provides pulse signal feedback and supports high-resolution RPM detection
Digital signal output: compatible with WOODWARD controllers, typically output in TTL, differential, or frequency signal format
Strong anti-interference ability: suitable for industrial electromagnetic environment, with good noise resistance design
High reliability: capable of long-term stable operation in high temperature, high humidity, and high vibration environments
3、 Technical parameters (typical, please refer to the model data sheet for details)
Parameter Description
The input power supply is usually 8-32 VDC (powered by the controller)
Output signal pulse output (digital frequency signal, TTL or differential square wave)
Speed measurement range: 0-20000 RPM (depending on the installation position of the sensor and the number of gear teeth)
Detecting magnetic gears or coding disks (usually requiring the use of magnetic steel gears)
Install interface thread type or flange type (depending on version)
Working temperature -40 ° C to+105 ° C (industrial grade)
Protection level IP65 or above (depending on the enclosure sealing structure)
