GIDINGS&LEWIS FSM490-B24伺服电机

 GIDINGS&LEWIS FSM490-B24伺服电机

1.产 品 资 料 介 绍：

高性能输出

电气特性

结构设计

控制与兼容性

英文资料：

High performance output

GIDINGS&LEWIS FSM490-B24 servo motors perform excellently in terms of power output. Its rated power is about 2.2 kW, achieving extremely high power density in a compact structure, ensuring that the equipment can also obtain sufficient power in a limited space. At a rated speed of 3000RPM, the motor can stably output a rated torque of approximately 9.3Nm and has a higher peak torque, which can meet the demanding requirements of high-speed operation and high-precision motion control scenarios. Whether in fast cutting of CNC machine tools or precise positioning of automated production lines, this motor can ensure the stability and accuracy of equipment operation with excellent torque performance.

Electrical Characteristics

This servo motor adopts 240VAC three-phase power supply, with a continuous current of about 9A. When facing high loads, the peak current can reach 19A, demonstrating strong high-speed and high load dynamic response capabilities. It can quickly adjust the output according to instructions, ensuring the timeliness and smoothness of equipment operation. Some models are equipped with 24VDC electromagnetic brakes, which immediately activate when the motor stops running, enhancing the stopping and holding performance of the equipment, greatly improving the safety of the equipment during operation, effectively preventing accidental movement or sliding, and providing reliable protection for industrial production.

structural design

The motor shaft diameter is approximately 19mm (3/4 inch), and this size design fully considers the matching requirements with various couplings and transmission devices, making it convenient for users to flexibly choose suitable transmission components according to actual application scenarios, achieving efficient power transmission. The shell is made of sturdy metal material and equipped with a durable bearing system. The overall structure can withstand high-intensity working conditions, ensuring stable operation of the motor even in harsh industrial environments. The motor weighs about 18kg and maintains a compact size while maintaining industrial grade durability, making it easy to install and integrate into various equipment.

Control and compatibility

The GIDINGS&LEWIS FSM490-B24 servo motor is designed specifically for use with Giddings&Lewis or Kollmorgen series servo drives. This targeted design ensures seamless connection between systems, allowing the motor and drive to perform at their best when working together, reducing signal transmission losses and delays, and improving overall system control accuracy and response speed. The motor is equipped with a high-resolution feedback interface, which can accurately detect the operating status of the motor through encoder/Hall sensor configuration and provide real-time feedback to the control system, facilitating closed-loop control and ensuring accurate positioning and stable operation of the motor even under complex working conditions.

2.产      品      展      示
